- Page 1 EVK User Guide Issue 1.0 Date 2019-12-23...
- Page 2 THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS. PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION. NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY IMPROPER OPERATIONS. THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO PRODUCT VERSION UPDATE OR OTHER REASONS.
-
Page 3: Table Of Contents
N25 EVK User Guide Contents Contents 1 Overview ....................6 2 About N25 EVB ..................7 3 Power and Connection ................9 3.1 Power Supply ..........................9 3.2 M5X0-PWR Board ........................9 4 Commissioning ..................11 Copyright © Neoway Technology Co., Ltd... - Page 4 N25 EVK User Guide About This Document About This Document Scope This document is applicable to N25 series. Audience This document is intended for system engineers (SEs), development engineers, and test engineers. Change History Issue Date Change Changed By 2019-06...
- Page 5 N25 EVK User Guide About This Document Related Documents Neoway_N25_Datasheet Neoway_N25_Product_Specifications Neoway_N25_HW_User_Guide Neoway_N25_AT_Command_Manual Copyright © Neoway Technology Co., Ltd...
-
Page 6: Overview
USB cable or serial-to-USB cable to commission the functions of the module. N25 Evaluation Kits (EVK) provides the following items: N25 EVB (including the N25 module) ⚫ 5V power adapter ⚫ M5X0-PWR USB-to-Serial cable ⚫ Others (antennas) ⚫ Copyright © Neoway Technology Co., Ltd... -
Page 7: About N25 Evb
In Figure 2-1, each interface and key of N25 is marked in red rectangles. Read this user guide carefully before using N25 EVB. If necessary, please refer to the schematic diagram and PCB file of the board. Table 2-1 lists each interface or button and their functions. Copyright © Neoway Technology Co., Ltd... - Page 8 Hold this button for more than 1 second to wake up from PSM_WAKE UP button PSM mode. Connect it to an antenna that covers the operating MAIN_ANT antenna connector frequencies of N25 when commissioning the EVB. HOST port Used for firmware upgrade and logs capturing. Copyright © Neoway Technology Co., Ltd...
-
Page 9: Power And Connection
1A or larger output current. Figure 3-1 5V power adapter 3.2 M5X0-PWR Board The M5X0-PWR board is developed on PL2303 chipset by Neoway and used to convert USB to UART. You can also choose another USB-to-UART cable/board based on FT2232, CP210X, and other chipsets. - Page 10 EVB at the other end. Among the 4-pin cables: Green ⚫ Module TXD, outputs 2.85V CMOS level Yellow ⚫ Module RXD, inputs maximum 3.3 V CMOS level Black ⚫ Ground ⚫ VBAT, main power input, 3.6V to 4.5V, 3.8 V recommended Copyright © Neoway Technology Co., Ltd...
-
Page 11: Commissioning
Hold the PWR_KEY button for 2 seconds, and the module starts up. Step 3: Install the PL2303 driver. Obtain the driver package from Neoway FAE or download it from the Internet if you use the serial-to-USB cable Neoway provided. Copyright © Neoway Technology Co., Ltd... - Page 12 Step 5: Send an AT command to detect the baud rate. The setting is available when value is displayed in the tool interface (indicating data can be transmitted between the module and the tool properly). Copyright © Neoway Technology Co., Ltd...
- Page 13 The module is registered to the network successfully when the NET indicator is on in green. ⚫ The PPP connection is activated successfully when the NET indicator flashes in green. ⚫ Step 6: Start to test the functions of N25 according to the product documentation Neoway provides. Copyright © Neoway Technology Co., Ltd...
