- Page 1 CONTENTS 1 TORQUE WRENCH LOADER Assembly Manual for ATWL250, ATWL750 and ATWL1000 Torque Cube Operation Manual...
-
Page 2: Table Of Contents
CONTENTS 2 CONTENTS CONTENTS ..........2 INTRODUCTION ........... 3 System Specifications ......... 3 System Components ........... 4 ASSEMBLY INSTRUCTIONS ......5 WARRANTY ..........6 Torque Cube Operation Manual... -
Page 3: Introduction
INTRODUCTION 3 INTRODUCTION ESCRIPTION Thank you for purchasing the Auditor Torque Wrench Loader from AIMCO. You have chosen a unit that accommodates dial, click and torque limiting torque wrenches. Torque wrench loaders are mechanisms designed to allow a user to easily apply load to a torque wrench via a large hand lever handle. -
Page 4: System Components
INTRODUCTION 4 YSTEM OMPONENTS Main carriage Crosshead with lever handle Assembling Reaction Post Wrench support Extension Bolts bracket The torque wrench loaders are shipped with the pictured components. Main carriage with angle bracket for mounting transducer bench stand, cross slide for appling load to torque wrench handle, reaction post, torque wrench handle support, extension plate for small wrenches (top of picture to bottom left). -
Page 5: Assembly Instructions
Warranty 5 ASSEMBLY INSTRUCTIONS Install cross slide onto main carriage as pictured. Install reaction post, and/or extension bracket and reaction post, to cross slide platform. Place torque wrench handle support on reaction post. Attach transducer to angle bracket on main carriage. When inserting torque wrench into transducer, it is very important to adjust the wrench handle support so the torque wrench handle is level. -
Page 6: Warranty
The warranty provision with respect to each such product may be amended by AIMCO from time to time in its sole discretion. The liability of AIMCO hereunder shall be limited to replacing or repairing, at its option, any products which are returned freight prepaid to AIMCO and which AIMCO determines to be defective as described above or, at AIMCO’s option, refunding the purchase price of such products. - Page 7 Notes:...
- Page 8 Corporate Headquarters 10000 SE Pine Street Ave. Cristóbal Colon 14529 Portland, OR 97216 Chihuahua, Chihuahua. 31125 800-852-1368 Mexico FAX 800-582-9015 011-52-(614) 380-1010 www.aimco-global.com FAX 011-52-(614) 380-1019 LIT-MAN984 Rev. 5/2014 Printed in USA ©2013 AIMCO...
