- Page 1 ZETA-NxP Series Modem Starter Kit Quick Start Guide Rev 1.0...
- Page 2 Please note Three SIM cards will not work with the ZETA-NxP-LTEM If you have purchased the ZETA-NxP as a standalone modem, you will need to purchase the accessories mentioned in this document separately. Visit www.siretta.com to find out where you can purchase these.
- Page 3 Setting up the ZETA-NxP Step 1. Insert a SIM card fully into the SIM slot. Once the SIM card has been correctly inserted, a click will be heard. Step 2. Screw the cellular antenna onto the antenna connector on the ZETA-NxP. Twist the antenna connector clock-wise until the antenna is firmly connected.
- Page 4 Step 3. Using the supplied RS232 cable, connect the RS232 male connector into the RS232 port on the ZETA-NxP. Connect the RS232 female connector (other end of the cable) into an RS232 port on your PC. RS232 to USB cable Step 4.
- Page 5 LTEM LED indication and table 2 for ZETA-NSP-LTEM LED indication. Flashing green LED indicates power on *If this step fails, please try again. If it fails a second time, please contact your Siretta representative or call us on +44 (0)118 976 9010.
- Page 6 NLP-LTEM LED indication and table 2 for ZETA-NSP-LTEM LED indication. VOLTS POWER Flashing green LED indicates power on *If this step fails, please try again. If it fails a second time, please contact your Siretta representative or call us on +44 (0)118 976 9010.
- Page 7 SAME FOR POWER SUPPLY / POWER CABLE Table 1. ZETA-NLP-LTEM LED indication LED colour State Red (STAT_LED) OFF: Module in power saving mode Fast flash during power on procedure. Once powered on the Green (GPIO 1) green LED will flash once every 30 seconds to indicate modem in powered on state Fast flash during power off procedure.
- Page 8 +44 (0)118 976 9000 +44 (0)118 976 9020 email sales@siretta.com www.siretta.com Siretta Ltd Basingstoke Road Spencers Wood Reading Berkshire RG7 1PW United Kingdom Company No. 08405712 VAT Registration No. GB163 04 0349 Rev 1.0...
