ASSEMBLY AND CARE INSTRUCTIONS
VERSION: 8920062 (Revised 10/17)
Canada and International
135 Forestview Road, Oro-Medonte
Ontario, Canada L3V 0R4
Toll-Free:
Telephone: (705) 325-2274
Fax:
service.ca@spiethamerica.com
UNEVEN PRO BARS ll
SALES AND SERVICE
spiethamerica.com
(800) 563-6479
(705) 325-1485
122PB
Toll-Free:
Telephone: (517)-999-8230
Fax:
service.usa@spiethamerica.com
USA
3327 Ranger Road
Lansing, MI 48906
(800) 331-8068
(517)-999-8245
Advertisement
Related Manuals for SPIETH America Uneven Pro Bars II
Summary of Contents for SPIETH America Uneven Pro Bars II
- Page 1 ASSEMBLY AND CARE INSTRUCTIONS UNEVEN PRO BARS ll 122PB VERSION: 8920062 (Revised 10/17) SALES AND SERVICE spiethamerica.com Canada and International 135 Forestview Road, Oro-Medonte 3327 Ranger Road Ontario, Canada L3V 0R4 Lansing, MI 48906 Toll-Free: (800) 563-6479 Toll-Free: (800) 331-8068 Telephone: (705) 325-2274 Telephone: (517)-999-8230 Fax:...
- Page 2 122PB UNEVEN PRO BARS ll Assembly Instructions Thank you for purchasing SPIETH America 122PB Uneven Pro Bars ll. We appreciate your business and value you as a customer. Your 122PB Uneven Pro Bars ll are manufactured of the finest materials and have been thoroughly inspected before leaving our plant.
- Page 3 122PB UNEVEN PRO BARS ll Assembly Instructions 1.1. Uneven Pro Bar Set-Up 1. Layout and mark the floor referring to the measurements in your tie-down system instructions. This will determine the position of the anchor holes and uneven bar assembly. Mark the base position and the location of the mount pin holes (See diagram on next page).
- Page 4 122PB UNEVEN PRO BARS ll Assembly Instructions Page 4 of 11...
- Page 5 122PB UNEVEN PRO BARS ll Assembly Instructions Page 5 of 11...
- Page 6 122PB UNEVEN PRO BARS ll Assembly Instructions 1.2. Apparatus Assembly 1. Set the two bases on the floor. Note the position of the short and long uprights (High Bar/Low Bar) when assembling so that you will not need to reposition the unit after assembly. 2.
- Page 7 122PB UNEVEN PRO BARS ll Assembly Instructions 1.3. Width Adjusters Assembly 1. Unscrew the width adjusters mounting hardware from the studs on the uprights. Install the width adjuster as shown on Fig. 2 below, and secure with mounting hardware. Figure 2 1.4.
- Page 8 122PB UNEVEN PRO BARS ll Assembly Instructions 2. Have two people stand the sides up, one person per side. Make sure the bases are properly installed on the mount pins as shown on page 3. 3. Attach one rail to the two short uprights. Note that the seam on the rail faces down. Ensure that the pin in each end of the rail is inserted all the way into the slot of the swivel head and has passed the Safety Screws.
- Page 9 122PB UNEVEN PRO BARS ll Assembly Instructions 1.5. Upright Alignment A visual inspection of your Uneven Bars will determine whether or not you have to adjust the Upright Alignment. If the Uneven Bars lean towards one side or unequally forward or backward, the Upright Alignment needs to be adjusted.
- Page 10 122PB UNEVEN PRO BARS ll Assembly Instructions 3. SAFETY WARNING Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death, from landing or falling on the neck, head, or other parts of the body. You assume a risk of serious injury in using this equipment.
