Ticket Mechanism（Entropy - Sting KC Cobra Operation & Instruction Manual

SERVICE AND TECHNICAL SUPPORT CALL: FAMILY FUN COMPANIES (708) 598-7320 WWW.FAMILYFUNCOMPANIES.COM
1 BASE：Base Mech
2 PROTECTION SKIRT： Prevent Player from reaching base
3 FIBERGLASS CAR：Main game（KC COBRA）
4 CHROME WHEEL COVER: Decoration
5 19"LCD MONITOR：For game video
6 STEERING WHEEL：Control car on video to move left and right
7 "JUMP" BUTTON：Press JUMP Button to jump car on video
8 TICKET/ DBV DOOR ：For ticket version or DBV version. Key GUA71.
9 COIN DOOR：Key GUA711
10 COIN BOX：Key GUA711, collect coin.
11 GAS PEDAL：Increment the speed of the car in the video.
12 SPEAKER COVER：Protects the audio speakers.
13 TRUNK：Key GUA711, reach to mainboard, amplifier board, main motor.
6-2 TICKET MECHANISM（ENTROPY）
How to fill the ticket
Open the Ticket Door, place the Tickets into the TICKET HOLDER.
Feed the Tickets into the TICKET MECH.
① Unclip and remove the Ticket retainier
For Ticket version only!
Picture 1
NOTE
。
Picture 2
