"BOP 2 WIN"
THE GAME OPERATION and
INSTRUCTION MANUAL
STING INTERNATIONAL, P.O. BOX 455, ELK GROVE VILLAGE, IL 60007 USA E-mail: sting2 @ rcn.com.
FOR ALL PARTS, SERVICE, AND TECHNICAL SUPPORT
PHONE: 708-598-3720 FAX: 708-598-3720
WWW.FAMILYFUNCOMPANIES.COM
STING INTERNATIONAL, © 2013 ALL RIGHTS RESERVED
Advertisement
Table of Contents
Related Manuals for Sting BOP 2 WIN
Summary of Contents for Sting BOP 2 WIN
- Page 1 “BOP 2 WIN” THE GAME OPERATION and INSTRUCTION MANUAL STING INTERNATIONAL, P.O. BOX 455, ELK GROVE VILLAGE, IL 60007 USA E-mail: sting2 @ rcn.com. FOR ALL PARTS, SERVICE, AND TECHNICAL SUPPORT PHONE: 708-598-3720 FAX: 708-598-3720 WWW.FAMILYFUNCOMPANIES.COM STING INTERNATIONAL, © 2013 ALL RIGHTS RESERVED...
-
Page 2: Table Of Contents
Bop 2 Win TABLE OF CONTENTS 1.Brief Introduction ......................1 2. Caution ........................1 2-1.Notice for Installation ..................1 2-2. Notice for Operation ..................1 3. Accessories ........................ 2 4. How to Play ......................... 2 5. Technical Parameter....................2 6. Appearance ......................... 3 7. -
Page 3: Brief Introduction
Bop 2 Win 1.Brief Introduction The novelty coin operated game; “Bop 2 Win” is intended for one Player. The Player try will attempt to use mechanical boxing glove "PUNCH" mechanism in order to “hit” the nose of the Clown character when the moving, lighted ticket score segment reaches the desired score. -
Page 4: Accessories
Bop 2 Win 3. Accessories Check that the following accessories are supplied. Name Remark Manual Power cord 3172(1pcs)；3157(1pcs) Micro switch Optical-coupler 4. How to Play Players will attempt to use the “PUNCH” plunger mechanism on the control panel to time the release of the boxing glove mechanism in order to hit the Clown character and stop the moving score. -
Page 5: Appearance
Bop 2 Win 6. Appearance MARQUEE TARGET SCORE PANEL “PUNCH” PLUNGER JACKPOT DISPLAY COIN AND TICKET DOOR... -
Page 6: All Parts Description And Location
Bop 2 Win 7. All Parts Description and Location SCORE LED CONTROL BOARDS EFFECT LED BOARD ARM MECHANISM ELECTROMAGNETIC COIL TICKET BIN SPEAKER... - Page 7 Bop 2 Win Inside the Back Door Panel: OPTICAL-COUPLER MOTOR SOLID STATE RELAY POWER SUPPLY TARGET LIGHT CONTROL BOARD MAIN PCB ON FLOOR POWER SWITCH AND FUSE PLATE...
-
Page 8: Component
Bop 2 Win 8. Component 8-1. Meter Board Function Setting Display：Coin and Ticket Meters and adjustment pushbuttons for accessing the MENU and OPTIONS settings. Total Coins：Numbers coins inserted to date. Total Tickets：Numbers of tickets dispensed to date. -
Page 9: Power Supply Input Panel
Bop 2 Win 8-2. Power Supply Input Panel Power Supply Jack: One power supply jack, located at the bottom right of the back of the machine. Fuse: There is an AC fuse in the fuse tube. Its specification is φ 6mm × 30mm. -
Page 10: Coin Mechanism
Bop 2 Win THIS COIN MECHANISM IS A MECHANICAL TYPE. IT HAS THE FUNCTION OF A SUPER MAGNET FOR GUARDING AGAINST COIN CHEAT SUCH AS ANTI-FALSE COIN, (“SLUG”) ANTI-FISHING, TAMPERING OR MACHINE INCLINATION. ACCEPTABLE COIN SIZE: Φ24MM～Φ26MM IN DIAMETER, 1.6MM～2.0MM THICK, EACH COUNTRY HAS VARIOUS SIZE COINS DEPENDING ON THE COIN MECHANISM. -
Page 11: Ticket Dispenser
Bop 2 Win Coin channel door Power off and take out Coin Mech. Refer to ARROW to open the coin channel door. Clean and maintain the Coin Mech. Use a small brush or wet towel to clean dirt and residue to clear any obstruction. -
Page 12: Error Codes
Bop 2 Win RESET BUTTON PICTURE 1 PICTURE 2 SENSOR PICTURE 3 PICTURE 4 PICTURE 5 Ticket entrance Fixed Sensor panel Ticket entrance Main body Ticket dispenser PCB board LED1 LED2 Ticket release button Ticket entrance: To load tickets. Mounting plate: To fix the ticket dispenser. -
Page 13: Pin Connection On Main Board
Bop 2 Win Error Code: E1: Alarm for Coin-In Timeout E2: Alarm for Ticket-Out Timeout 9. PIN Connection on Main Board Specificati Port Port Program Wiring on Of Function Code Items Color Wiring Ticket Power supply for Φ0.3 Dispenser Yellow +12v Φ0.3... - Page 14 Bop 2 Win Φ0.3 Purple speaker lamp green Out2.1 OUT10 Φ0.3 Gray speaker lamp blue Out2.2 OUT11 Φ0.3 Out2.3 OUT12 Φ0.3 Out2.4 OUT13 Φ0.3 Out2.5 OUT14 Φ0.3 Out2.6 OUT15 Φ0.3 Out2.7 OUT16 Φ0.3 Out3.0 OUT17 Φ0.3 Out3.1 OUT18 Φ0.3 Out3.2 OUT19 Φ0.3...
-
Page 15: Function And Score Setting Instruction
Bop 2 Win right 4,2,8,2,6,2,4,2score lamps. 16 Φ0.3 +12v Yellow post lamp panel Φ0.3 Brown 2:JP1-1 big prize lamp, Φ0.3 Green 2 motor drive for the clown action, 4 reflector lamp drive 5 box spotlight control， 6 front-panel Φ0.3 White flashing light 1,2,3.JP2-1 nixie tube... - Page 16 Bop 2 Win MENU and OPTIONs Directory MENU # OPTION# *NOTES FACTORY DEFAULT SETTING DISPLAYED ON THE JACKPOT SCORE AND TICKET DISPLAY MENU# OPTION# ACTION Return to Game Play Free Play 1 Credit Play 02 * 2 Credit Play *...
- Page 17 Bop 2 Win Jackpot Level Win Ratio: 1 in 40 Jackpot Level Win Ratio: 1 in 45 Jackpot Level Win Ratio: 1 in 50 Jackpot Level Win Ratio: 1 in 60 Jackpot Level Win Ratio: 1 in 70 Jackpot Level Win Ratio: 1 in 80...
- Page 18 Bop 2 Win Option Jackpot Win Ratio: 1 in 250 Option Jackpot Win Ratio: 1 in 260 Option Jackpot Win Ratio: 1 in 270 Option Jackpot Win Ratio: 1 in 280 Option Jackpot Win Ratio: 1 in 290 Option Jackpot Win Ratio: 1 in 300...
-
Page 19: Test Functions
Test: Coin mechanisms – coin entered:“ding” Test: Ticket mech: Press “BOP” dispense one ticket Test: Test: Flash Jackpot display- all 4 blocks Test: Audio THIS GAME IS THE ORIGINAL INTELLECTUAL PROPERTY OF STING INTERNATIONAL © COPYRIGHT 2013 ALL RIGHTS RESERVED...
