- Page 1 N1 Installation Guide N1 Installation Guide Version 1.0 Date: August 2, 2016 Yeastar Information Technology Co. Ltd.
-
Page 2: Table Of Contents
1. Preparation before Installation ................2 1.1 Packing List ....................2 1.2 Specifications and Operating Environment ............2 2. N1 Overview ......................3 2.1 N1 Front Panel ....................3 2.2 N1 Rear Panel ....................4 3. Installation ......................5 3.1 Placement Instructions ..................5 3.2 Connect Your N1 ..................... -
Page 3: About N1
Yeastar N1 Telephone System comprises N1 Core Server and Expansion Units that deliver flexible telephony interfaces customization and efficient office communication to SMB. Deploy N1 to have analog phones, PSTN lines and other trunkings that best suit your needs in one system. -
Page 4: Preparation Before Installation
N1 Installation Guide 1. Preparation before Installation 1.1 Packing List Upon receiving Yeastar N1 gift box, please open the package and check if all the items are supplied as N1 Packing List. If there is any problem, please contact your provider. -
Page 5: N1 Overview
2. N1 Overview 2.1 N1 Front Panel HDD1 HDD Slots HDD2 POWER Figure 2-1 N1 Front Panel Table 2-1 N1 Front Panel - LED Description LED Status Description The power is switched on. POWER The power is switched off. Blinking N1 is running properly. -
Page 6: N1 Rear Panel
2.2 N1 Rear Panel CONSOLE EXPANSION POWER INLET POWER SWITCH RESET Figure 2-2 N1 Rear Panel Table 2-2 N1 Rear Panels–Port Description Port Description Reset Button Press for 10 seconds to reset the system. Console Port Used for service and maintenance. -
Page 7: Installation
Connect one end of a network cable to the LAN port of N1, and the other end to your company’s switch or router. Note: if you want to use WAN port, you need to log in the N1 web GUI to enable WAN port. -
Page 8: Basic Configurations
N1 Installation Guide an electrical outlet. Press the On switch to power on the N1. The device will start booting. In the meantime, users would see that the “POWER” and “RUN” indicator lights turn on. Note: please switch off the power before plugging or unplugging the cables. -
Page 9: Network Settings
If the LAN port is connected to the company’s LAN, please configure the correct IP address and corresponding subnet mask. Note: please note that after changing the IP address of LAN port, N1 should be rebooted to make the new changes to take effect.
