BIN 34
Fitting instructions
IMPORTANT - The unit has a maximum loading limit of 25kg including door.
Bin to suit 600mm wide cabinet using 18mm thick carcase material.
All fixings supplied must be used for installation.
Parts
A
x12 3.5 x 16mm screw
B
x4
3.5 x 14mm screw
C
x4
Screw (M4 x 8mm)
D
x2
Screw (M6 x 15mm)
E
x2
Screw (M5 x 8mm)
F
x4
Screw (M5 x16mm)
G
H
J
K
1
Mark screw positions for lid brackets and runners on
both cabinet sides.
478mm
422mm
3
Fit the lid brackets and runners to cabinet sides using
screws A.
Issue date: 23.08.12
L
Door bracket LH x1
N
Lid x1
Lid bracket LH x1
P
Lid bracket RH x1
Runner LH x1
Runner RH x1
Frame x1
Please ensure that all the above fittings are present before
installation begins.
418mm
290mm
194mm
37mm
229mm
389mm
Note: Dimensions are for
horizontal slotted holes.
18mm
G
J
H
K
M
Door bracket RH x1
Q
Container x2
2
Lift the locking levers and remove the front part of
each runner.
Ensure shoulder of bracket
faces outwards.
4
Assemble each runner until the locking levers are
securely attached.
J
Tools required
Dimensions
- maximum
484mm
495mm
J and K
K
564mm
