HANGBAR
QTY. 1
TOP UPRIGHT
QTY. 2
TOOLS INCLUDED
ADJUSTABLE
CONNECTOR
QTY. 2
BOTTOM
UPRIGHT
QTY. 2
WRENCH
BASE
QTY. 1
CASTER
QTY. 4
ALLEN KEY
PSBB60ADJ
ASSEMBLY
INSTRUCTIONS FOR:
PSBB60ADJ
1
SCREW IN THE CASTERS TO THE BASE AS SHOWN USING PROVIDED WRENCH.
2
STEP 2A
STEP 2B
STEP 2A
BY HAND, SCREW IN BOTTOM UPRIGHTS.
STEP 2B
TO FULLY TIGHTEN UPRIGHT, PLACE
INCLUDED WRENCH INTO PIPE SLOTS AS
SHOWN. TIGHTEN FULLY
SHEET 1 OF 2
Advertisement
Related Manuals for Econoco PSBB60ADJ
Summary of Contents for Econoco PSBB60ADJ
- Page 1 ASSEMBLY INSTRUCTIONS FOR: PSBB60ADJ SCREW IN THE CASTERS TO THE BASE AS SHOWN USING PROVIDED WRENCH. HANGBAR QTY. 1 TOP UPRIGHT QTY. 2 TOOLS INCLUDED ADJUSTABLE CONNECTOR QTY. 2 STEP 2B BOTTOM UPRIGHT QTY. 2 WRENCH BASE STEP 2A QTY. 1 BY HAND, SCREW IN BOTTOM UPRIGHTS.
- Page 2 LOOSEN HAND WHEEL ON BOTH SIDES • DROP HANGBAR INTO DESIRED HEIGHT • LOCK IN POSITION BY TIGHTENING THE TIGHTEN SET SCREW USING HAND WHEEL ON BOTH SIDES THE ALLEN KEY TO LOCK ADJUSTABLE CONNECTOR IN PLACE. PSBB60ADJ SHEET 2 OF 2...
