with an impedance equal or greater than this rating. A speaker output rated "8 ohms min" can safely
be used with 8 or 16 ohms loads.
8. Specifications
8.1 MIDI Mapping
8.1.1 Program Change (PC)
Each preset on the Torpedo Captor X has a single program number. The preset 001 of the machine is
triggered by a MIDI PC 1, you can address the 128 presets, with MIDI PC 1 to MIDI PC 128. This way, it
is possible to randomly access the preset by sending the appropriate MIDI PC number.
8.1.2 Control change (CC)
The following table indicates the Control Change numbers for every parameter, as well as their range
and behavior.
Parameter CC# Range
Cab/mic
On/Off 6
Unused 7
Cab 8
File A 9
File B 10
Folder A 11
Folder B 12
Mic A 13
Distance A 14 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
Center A 15 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
Position A 16
Level A 35 0-107 0 = -95dB ; 95 = 0dB ; 107 = 12dB
Phase A 36
Mute A 37
Mic B 38
Distance B 39 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
Center B 40 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
Position B 41
Level B 42 0-107 0 = -95dB ; 95 = 0dB ; 107 = 12dB
User's manuals - https://wiki.two-notes.com/
31/36
Simulation & IR Loader modes
0-1 0 = Off ; 1 = On
0-1 0 = Off ; 1 = On
0-x 0 = Cab #0 ; 1 = Cab #1...
0-x 0 = File #0 ; 1 = File #1...
0-x 0 = File #0 ; 1 = File #1...
0-3 0= User 0 ; 1= User1; 2 = User 2 ; 3 = User 3
0-3 0= User 0 ; 1= User1; 2 = User 2 ; 3 = User 3
0-7 0 = Mic #1 ; 1 = Mic #1...
0-1 0 = Back : 1 = Front
0-1 0 = Normal ; 1 = Invert
0-1 0 = Off (no mute) ; 1 = On (mute)
0-7 0 = Mic #1 ; 1 = Mic #1...
0-1 0 = Back : 1 = Front
Behavior
