CONTROL PANEL
Do not use abrasive cleaners, steel-wool pads, gritty washcloths
or some paper towels. Damage may occur.
Glass cleaner and soft cloth or sponge:
Apply glass cleaner to soft cloth or sponge, not directly on
panel.
OVEN CAVITY
Food spills should be cleaned when oven cools. At high
temperatures, foods react with porcelain and staining, etching,
pitting or faint white spots can result.
On some models, the oven door can be removed. See "Oven
Door" first.
Steel-wool pad
Oven cleaner:
Follow product label instructions. Do not let cleaner contact
gasket, thermostat or exterior surfaces. Line the floor with
newspaper.
OVEN RACK AND ROASTING RACK
Steel-wool pad
BROILER PAN AND GRID
Do not clean in the Self-Cleaning cycle (on some models).
Mildly abrasive cleanser:
Scrub with wet scouring pad.
Solution of
cup (125 mL) ammonia to 1 gal. (3.75 L) water:
Soak for 20 minutes, then scrub with scouring or steel-wool
pad.
Oven cleaner:
Follow product label instructions.
Porcelain enamel only, not chrome
Dishwasher
OVEN DOOR GLASS (on some models)
Glass cleaner and paper towels or nonabrasive plastic
scrubbing pad

Oven Light

(on some models)
The oven light is a standard 40-watt appliance bulb. Press the
manual oven light switch (on some models) on the backguard to
turn on and off. This oven does not have an automatic light
switch.
Before replacing, make sure the oven and cooktop are cool and
the control knobs are off.
To Replace:
1. Unplug range or disconnect power.
2. Turn bulb counterclockwise to remove from socket.
3. Replace bulb.
4. Plug in range or reconnect power.

Oven Door

For normal range use, it is not suggested to remove the oven
door. However, if removal is necessary, make sure the oven is off
and cool. Then, follow these instructions. The oven door is heavy.
To Remove:
1. Open the oven door. Insert hinge pins, included with your
range, into both hinge hangers. Do not remove the pins while
the door is removed from the range.
2. Grasp the door on the sides with your fingers on the front of
the door and your thumbs on the inside surface.
3. Pull door straight up, then toward you. Do not remove hinge
pins until the door is replaced on the range.
To Replace:
1. Grasp the door on the sides with your fingers on the front of
the door and your thumbs on the inside surface.
2. Hold oven door so that the top edge of each door slot is
horizontal. Insert door hinge into the hinge slots.
3. Tilt top of door toward range. Insert bottom door hinge notch
down onto front frame edge.
4. Open the door completely and remove the hinge pins. Save
hinge pins for future use.
5. Close the door slowly to assure door side panel clearance
and proper hinge engagement.
11
