2.1.2 CHANGING IMPLEMENTS
Up to three separate implements can be selected on the Loup
Elite. Unless pre-con gured by Loup, all three implements will
default as gravity drills. To switch implements simply select
the "My Saved Implements" button and select the implement
number you' d like. From here you can con gure the type of
implement, make, width and so forth. All implement settings are
automatically saved as they are made.

3.0 INSTALL/SETUP MENU

Located by selecting "Menu" and "Install
Setup". e Install/Setup Menu is used
to Learn a New system, Add new sensors
to your existing system or Remove speci c sensors from your
implement.

3.1 LEARN NEW SYSTEM

Select "Learn New System" if your
monitor did not come pre-programmed
or you wish to relearn all sensors.
1. Start by unplugging all sensors on the implement and then
selecting "Learn New System". A popup will warn you that
all current sensors will be overwritten. Select "Yes, Learn
New System".
2. e monitor will prompt you to Plug In Fbus sensors (all
us sensors have a 3 pin connector with white, black
and green wires) in the following order.
prompted will automatically be learned upon connecting the
3 pin connector.
1. Speed Sensor: Sha mounted ground speed sensor
2. Li Switch
3. Rate Cal Sensor
LOUP ELECTRONICS • 1-877-489-5687 • WWW.LOUPELECTRONICS.COM
3.
4.

3.2 REMOVE A SENSOR

Select this option to remove a sensor
from your existing system.
1.
2.
3.

3.3 ADD A SENSOR

Select this option to add a new sensor to
your existing system.
1.
2.
3.
e sensor being
4. Population/Row Sensors: Up to 32 sensors
5. Bin Level: Up to 6 bin level sensors
6. Sha Speed Sensor: Up to 6 possible Sha RPM
Sensors
7. Fan: Up to 3 Fan RPM sensors
8. Blockage Module: Up to 12 Modules with 192
runs of product detection.
It is likely your system will not be con gured for the
maximum possible sensors or even certain types of sensors
the Loup Elite is capable of.
is Sensor" button to
Use the "Skip
advance ahead one sensor at a time.
Use the "Skip is Type of Sensor"
to advance to the next category of
sensors.
When you've reached the end of the list of sensors, you will
be prompted with "Manual Learn Complete". Push "Ok" to
nish.
Select the type of sensor
you wish to remove.
Use the Le and Right
Arrows to navigate to the
sensor number you wish
to remove.
Select the "Remove
Sensor" button to
complete the removal.
Select the type of sensor
you wish to add.
Use the Le and Right
arrow buttons to navigate
to the sensor number you
wish to add.
Select the "Add Sensor"
button to complete the
sensor addition.
7
