- Page 1 Replacement Guide for the HT1x00 Satellite Modem 1039585-0001 Revision G February 9, 2016 11717 Exploration Lane, Germantown, MD 20876 Phone (301) 428-5500 Fax (301) 428-1868/2830...
- Page 2 Copyright © 2012-2016 Hughes Network Systems, LLC All rights reserved. This publication and its contents are proprietary to Hughes Network Systems, LLC. No part of this publication may be reproduced in any form or by any means without the written permission of Hughes Network Systems, LLC, 11717 Exploration Lane, Germantown, Maryland 20876.
-
Page 3: Before You Begin
Follow the instructions in this booklet to replace your old HT1x00 satellite modem with the new one you just received. In these instructions, “old modem” refers to the satellite modem you are currently using and “new modem” refers to the replacement you just received; likewise, “old power supply”... - Page 4 Disconnecting the old modem and old power supply Refer to Figure 2 when performing the procedures in this section. Figure 2: Disconnecting the old modem and old power supply The modem does not have a power (off/on) switch. Before disconnecting the old modem and old power supply, you must unplug the power supply’s power plug from the surge protector or power outlet.
- Page 5 Connecting the new modem and new power supply Figure 3 Refer to when performing the procedures in this section. Figure 3: Connecting the new modem and new power supply Plug the new modem’s power supply plug into an outlet or surge protector only after the rest of the cables are connected to the new modem.
- Page 6 3. Connect the new power supply to the DC IN port of the new modem. Ensure the power supply cable is seated correctly in the modem. Figure 4 shows an example of a correctly seated and an incorrectly seated cable. Figure 4: Seating the power supply cable in the new modem It is very important to make sure all connections are tight.
- Page 7 Checking modem operation This section explains how to make sure the new modem is ready to use. Make sure you have waited approximately 30 minutes since you plugged in the modem’s power cord. 1. On your PC, use a browser (such as Google Chrome) to go to any Internet website.
-
Page 8: If You Need Assistance
If you need assistance If you have a question or need assistance, call HughesNet Customer Care, toll free, at 1-866-347-3292. Make sure you have fully read these instructions before you call. If you cannot complete the replacement procedure, it may be that the replacement was not authorized or that the 30-day authorization period has expired. - Page 9 Packing the old modem to return it to Hughes To avoid being charged for unreturned equipment, return the old modem to Hughes within 30 days from the date the new modem is shipped to you. Please return your old modem, old power supply, and any cables you are not using. 1.
- Page 10 Figure 7: Return label example showing RMA number and tracking number 1039585-0001 Revision G...
- Page 11 Shipping the package To ship the equipment, take the box to any staffed UPS location or give the box to any UPS driver. You can find UPS locations online at www.ups.com/dropoff. Follow the procedure below once you have navigated to the website. 1.
