Summary of Contents for POLA HP11
- Page 1 TH-D...
- Page 2 TECHNICAL DATA TABLE TABELLA DATI TECNICI TH-D TEMPERATURE -50 °C / +115 °C RANGE SONDE TEMPERATURE -30 °C / +100 °C RANGE POWER ~220-240 V SUPPLY FREQUENCY 50-60 Hz FUSE PROTECTION en - Disposal of your old product it - Smaltimento del prodotto - You product is designed and manufactured with high - Questo prodotto è...
- Page 3 FIGURES FIGURE Display Control Panel - Pannello Di Controllo Temperature Sensor - Sensore Di Temperatura Power Cord - Cavo Di Alimentazione Digital Thermostat - Termostato Digitale Power Cord - Cavo Di Alimentazione Connector - Connettore...
- Page 4 HP11 SL 4.0 Single-level thermostat Handbook MAIN SETTINGS (Run Mode). TEMPERATURE SETTING. Press SET (key lamp flashes): This message will be displayed in alternance with the °Set 1 temperature value . Press + or - to modify. Press SET to confirm.
-
Page 5: Preset Programs
COOL t.SEt TEMPER. INSTALLATION How to connect the line HP11 Connect 230V line on terminals L-N. Protect supply with adequate fuse. How to connect the contacts Connect terminals on the terminal block (contacts up to 4AMP.AC1) to the loads as shown in the diagram. -
Page 6: Funzionamento Normale
HP11 SL 4.0 Termostato singolo livello Manuale d'uso FUNZIONAMENTO NORMALE IMPOSTAZIONE SET TEMPERATURA Premere SET: sul visore comparirà questo messaggio in alternanza al valore impostato di °Set Temperatura. Agire su + o - per variarlo, premere SET a conferma. t.SEt = 25.0°... -
Page 7: Programmi Preimpostati
TEMPER. INSTALLAZIONE iù Allacciamento linea HP11 Allacciare la linea ai terminali L-N della morsettiera; proteggere la linea di alimentazione con fusibile adeguato. Allacciamento contatti Allacciare i terminali della morsettiera (contatti fino a 4AMP.AC1) ai carichi da comandare in accordo allo schema stabilito. - Page 8 MCS Italy S.p.A. Via Gardesana 11, -37010- Pastrengo (VR), Italy info@mcsitaly.it MCS Central Europe Sp. z o.o. ul. Magazynowa 5A, 62-023 Gądki, Poland office@mcs-ce.pl MCS Russia LLC ul. Transportnaya - 22 ownership 2, 142802, STUPINO, Moscow region, Russia info@mcsrussia.ru MCS China LTD Unit A1, No.
