Pet-immune PIR Motion Detector

The motion detector is designed for use on interior walls and is set to Home Mode
by default. Whenever the sensor detects movement (only while the alarm is armed),
a push notification including the sensor name will automatically be sent to the
registered users, and the hub's internal siren will sound immediately.
LED ON / OFF
Infrared Sensor
Blinks continuously
Blinks once
Blinks once every 3 seconds
Tamper Switch
The tamper switch will trigger an alarm notification if an unauthorized attempt is
made to remove the cover of the detector from its housing.
Detection Area
Top View
1. Detection Window
2. LED Indicator
3. Snap Joint
4. Test Button
5. Bracket
Infrared Sensor
Tamper Switch
Zone Setting
Motion detector is performing a self-test
Motion detected
Low battery indication, please change the battery
immediately
Side View
2.5m
09
