QnA Series
CPU Direct Driver
1
System Configuration....................................................................................................... 3
2
Selection of External Device ............................................................................................ 6
3
Example of Communication Setting ................................................................................. 7
4
Setup Items ...................................................................................................................... 9
5
Cable Diagram ............................................................................................................... 13
6
Supported Device........................................................................................................... 17
7
Device Code and Address Code.................................................................................... 19
8
Error Messages.............................................................................................................. 21
1
Mitsubishi Electric Corporation
Advertisement
Related Manuals for Mitsubishi Electric QnA Series
Summary of Contents for Mitsubishi Electric QnA Series
-
Page 1: Table Of Contents
Mitsubishi Electric Corporation QnA Series CPU Direct Driver System Configuration....................... 3 Selection of External Device .................... 6 Example of Communication Setting ................. 7 Setup Items ........................9 Cable Diagram ....................... 13 Supported Device......................17 Device Code and Address Code..................19... - Page 2 QnA Series CPU Direct Driver Introduction This manual describes how to connect the Display and the External Device (target PLC). In this manual, the connection procedure will be described by following the below sections: System Configuration "1 System Configuration" (page 3)
-
Page 3: System Configuration
QnA Series CPU Direct Driver System Configuration The system configuration in the case when the External Device of Mitsubishi Electric Corp. and the Display are connected is shown. Setting Cable Series Link I/F SIO Type Example Diagram Setting Cable Q4A CPU... - Page 4 QnA Series CPU Direct Driver IPC COM Port When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please refer to the IPC manual for details. Usable port Usable Port Series RS-232C...
- Page 5 QnA Series CPU Direct Driver DIP switch setting: RS-422/485 (4 wire) DIP switch Setting Description Reserved (always OFF) SIO type: RS-422/485 Output mode of SD (TXD) data: Always output Terminal resistance (220Ω) insertion to SD (TXD): None Terminal resistance (220Ω) insertion to RD (RXD): None...
-
Page 6: Selection Of External Device
Corporation". Select a model (series) of the External Device to be connected and connection method. Select " QnA Series CPU Direct". Check the External Device which can be connected in " QnA Series CPU Direct" in system Driver configuration. "1 System Configuration" (page 3) Check this option when you synchronize the system data area of Display and the device (memory) of External Device. -
Page 7: Example Of Communication Setting
QnA Series CPU Direct Driver Example of Communication Setting Examples of communication settings of the Display and the External Device, recommended by Pro-face, are shown. Setting Example 1 Setting of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. - Page 8 QnA Series CPU Direct Driver Setting Example 2 Setting of GP-Pro EX Communication Settings To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace. Device Setting There is no setting on the External Device. The speed automatically switches according to the Display setting.
-
Page 9: Setup Items
QnA Series CPU Direct Driver Setup Items Set communication settings of the Display with GP-Pro Ex or in off-line mode of the Display. The setting of each parameter must be identical to that of External Device. "3 Example of Communication Setting" (page 7) - Page 10 QnA Series CPU Direct Driver Setup Items Setup Description Use an integer from 1 to 127 to enter the time (s) for which the Display waits for the Timeout response from the External Device. In case of no response from the External Device, use an integer from 0 to 255 to enter how Retry many times the Display retransmits the command.
- Page 11 QnA Series CPU Direct Driver Settings in Off-Line Mode • Refer to the Maintenance/Troubleshooting manual for information on how to enter off-line mode or about the operation. Maintenance/Troubleshooting Manual "2.2 Off-line Mode" Communication Settings To display the setting screen, touch [Device/PLC Settings] from [Peripheral Settings] in off-line mode. Touch the External Device you want to set from the displayed list.
- Page 12 QnA Series CPU Direct Driver Setup Items Setup Description Use an integer from 1 to 127 to enter the time (s) for which the Display waits for the Timeout (s) response from the External Device. In case of no response from the External Device, use an integer from 0 to 255 to enter how Retry many times the Display retransmits the command.
-
Page 13: Cable Diagram
QnA Series CPU Direct Driver Cable Diagram The cable diagram shown below may be different from the cable diagram recommended by Mitsubishi Electric Corp. Please be assured there is no operational problem in applying the cable diagram shown in this manual. - Page 14 QnA Series CPU Direct Driver Cable Diagram 2 Display Cable Notes (Connection Port) Mitsubishi A connection cable by Pro-face (COM1) CA3-CBLA-01 (5m) AGP-3302B (COM2) (COM2) The cable length must be Your own cable 500m or less. All GP models except AGP-3302B All ST models except AST-3211A Only the COM port which can communicate by RS-422/485 (4 wire) can be used.
- Page 15 QnA Series CPU Direct Driver Cable Diagram 3 Display Cable Notes (Connection Port) COM port conversion adapter by Pro-face CA3-ADPCOM-01 2-port adapter cable for AGP by Pro-face CA3-MDCB11 (5m) (COM1) AGP-3302B (COM2) 2-port adapter II by Pro-face (COM2) GP070-MD11 Your own cable...
- Page 16 QnA Series CPU Direct Driver B) When using your own cable and 2-port adapter II (GP070-MD11) by Pro-face. Terminal block D-sub 9 pin (socket) Shield Termination resistance Signal name Signal name 330Ω 1/4W GP070-MD11 Display External Device Shell Your own cable C) When using online adapter (CA4-ADPONL-01), 2-port adapter cable for AGP (CA3-MDCB11) by Pro-face and 2-port adapter II (GP070-MD11) by Pro-face.
-
Page 17: Supported Device
QnA Series CPU Direct Driver Supported Device Range of supported device address is shown in the table below. This address can be specified as system data area. Device Bit Address Word Address 32 bits Notes Input Relay X0000 - X1FFF... - Page 18 QnA Series CPU Direct Driver Device Bit Address Word Address 32 bits Notes File Register (Normal) ------ R00000 - R32767 File Register (Block switching ZR0000000 - ------ is not necessary) ZR1042431 ------ 0R00000 - 0R32767 ------ 1R00000 - 1R32767 ------...
-
Page 19: Device Code And Address Code
QnA Series CPU Direct Driver Device Code and Address Code Use device code and address code when you select "Device Type & Address" for the address type in data displays. Device Device Code Device Address Code Name (HEX) Input Relay... - Page 20 QnA Series CPU Direct Driver Device Device Code Device Address Code Name (HEX) 0010 Word Address 0011 Word Address 0012 Word Address 0013 Word Address File Register (0R - 31R) 002C Word Address 002D Word Address 002E Word Address 002F...
-
Page 21: Error Messages
QnA Series CPU Direct Driver Error Messages Error messages are displayed on the screen of Display as follows: "No. : Device Name: Error Message (Error Occurrence Area)". Each description is shown below. Item Description Error No. Name of External Device where error occurs. Device name is a title of External Device set Device Name with GP-Pro EX.(Initial value [PLC1]) - Page 22 QnA Series CPU Direct Driver GP-Pro EX Device/PLC Connection Manual...
