  • Page 1 LINK 105 Installation Guide...
  • Page 2: Table Of Contents

    Installing LINK 105 in your vehicle........
  • Page 3 RFC1321-based (RSA-free) MD5 library........Webfleet Solutions Limited Warranty....... . 25...
  • Page 4: Read Me First

    With the LINK 105 you can retrieve fuel consumption data over the OBD-II connector in your vehicle and see this in WEBFLEET in real time. LINK 105 works together with the LINK 7xx/5xx/4xx via Bluetooth® wireless technology and therefore requires...
  • Page 5: Safety First

    Repairs must be carried out by authorised and qualified personnel only. Never replace damaged parts of the unit yourself. Send the defective unit to Webfleet Solutions for repair. Only the qualified staff of Webfleet Solutions are authorised to repair or...
  • Page 6 Damage to the device Short-circuits inside the unit can be caused by contact with water or other liquids. The unit may be damaged by contact with water. Use and store the unit in an area protected from water.
  • Page 7: Before The Installation

    If you need the OBD-II connector in your vehicle, for example for maintenance, remove your LINK 105 from the connector and reconnect it afterwards. Important: To remove the LINK 105 from the OBD-II connector, pull on the handle of the LINK 105 and not the device itself as this may cause damage.
  • Page 8: Installing Your Link 105

    LINK 105, which you can find on the label on the OBD-II plug. Install your LINK 105 in your vehicle. Important: If the LINK 105 has been used in another vehicle before, you need to reset the device before you start the engine of your vehicle, otherwise the calculation of the fuel consumption may be incorrect.
  • Page 9: Configuring A Bluetooth Connection With The Link Toolkit App

    The app starts searching for LINK devices in your area. This can take a few seconds. 4. Tap the LINK device in the list to which you want to connect the LINK 105. The LINK Toolkit app displays the status screen for the selected LINK device.
  • Page 10: Installing Link 105 In Your Vehicle

    The OBD accessory view is shown. 9. Tap on the field for Type and select LINK 105 from the drop-down list. 10. Enter the Bluetooth address of the LINK 105 in the field for Bluetooth address (14 characters). 11. In the fields for Engine power (kW) and Engine size (in ccm), enter the power in kW and the size in ccm of the engine of your vehicle.
  • Page 11 Important: You can damage your vehicle and the LINK 105 when you continue the installation while the engine of your vehicle is running. 3. Insert the OBD-II plug of your LINK 105 into the OBD-II connector of your vehicle. Make sure the plug is fully inserted so it cannot drop off.
  • Page 12: Diagnostics

    Your LINK 105 shows system states using the blue and the green LED individually and in combination. The following system states of the LINK 105 are shown by both the blue and the green LED in combination. Green and Blue LED...
  • Page 13: Resetting Your Link 105

    Resetting your LINK 105 If you have operated the LINK 105 in another vehicle before, if you encounter errors with your LINK 105 or your LINK 105 is not working as expected you need to reset the device. 1. Turn off the engine of your vehicle.
  • Page 14 Fuse protection Internally fused with 1A, fuse is not resettable or replaceable, fuse must be replaced by Webfleet Solutions Temperature Operation: -30 °C to +70 °C / -22 °F to 158 °F Storage: -40 °C to +80 °C / -40 °F to +176 °F...
  • Page 15: Addendum

    Addendum Important Safety Notices and Warnings Safety messages Important! Read before use! Death or serious injury could result from failure or partial failure to follow these warnings and instructions. Failure to properly set up, use, and care for this device can increase the risk of serious injury or death, or damage to the device.
  • Page 16: Prohibited Uses

    Bluetooth : 2.5 mW, 4dBm. ▪ Hereby, Webfleet Solutions declares that the radio equipment type telematics black box is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.webfleet.com/...
  • Page 17: Exposure Limits

    WEBFLEET If your vehicle is configured to connect to WEBFLEET services, it will collect information for the purposes of the WEBFLEET service while the vehicle is in use in association with other WEBFLEET equipment installed in the vehicle. The following information is continuously collected: vehicle location, g-force/acceleration data, and engine-related data such as fuel consumption, valve positions, engine speed, and odometer value.
  • Page 18: Triman Logo

    Triman logo Technical Specifications Supply voltage 12 V/24 V (min. 9 V to max. 30 V) Maximum power consumption At 14 V: 0.025 W At 28 V: 0,0015 W Frequencies ® Bluetooth : 2402-2480 MHz FCC information for the user THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES Federal Communications Commission (FCC) Statement This equipment radiates radio frequency energy and if not used properly - that is, in strict...
  • Page 19: Responsible Party In North America

    Webfleet Solutions, the FCC may withdraw the user’s right to operate the equipment. For customers in the USA, the following booklet prepared by the Federal Communications Commission may be of help: "How to Identify and Resolve Radio-TV Interference Problems".
  • Page 20: Mexico

    IMPORTANT NOTE IC Radiation Exposure Statement: ▪ This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. ▪ This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. ▪...
  • Page 21: Notice For South Africa

    This document may not be copied without the prior written consent from Webfleet Solutions B.V. WEBFLEET Telematics Service Platform To use the LINK 105 you need a valid and active WEBFLEET Telematics Service Platform subscription. Accessories supplied with this device Basic installation guide ▪...
  • Page 22: Terms And Conditions: Limited Warranty And Eula Reference

    Terms and conditions: Limited warranty and EULA reference Our terms and conditions, including our limited warranty and end user license terms apply to this product; visit https://www.webfleet.com/legal...
  • Page 23: Copyright Notices

    Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Webfleet Solutions is under licence. Other trademarks and trade names are those of their respective owners. Copyright (c) 2018 - Tcl/Tk - Regents of the University of California, Sun Microsystems, Inc., Scriptics Corporation,...
  • Page 24 This software is provided 'as-is', without any express or implied warranty. In no event will the authors be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the following restrictions: The origin of this software must not be misrepresented;...
  • Page 25: Webfleet Solutions Limited Warranty

    HOW TO MAKE A WARRANTY CLAIM 3 In order to make a claim of a Defect, you must contact Webfleet Solutions during the Warranty Period via www.webfleet.com to explain the Defect and to obtain an RMA number (Return Materials Authorization) if necessary. You must return the Hardware during the Warranty Period, along with the RMA number provided by Webfleet Solutions and an explanation of the Defect, to the address provided to you by Webfleet Solutions.
  • Page 26 8 This Limited Warranty cannot be transferred to any other person. LIMITATION OF LIABILITY 9 Neither Webfleet Solutions nor its suppliers shall be liable to you or to any third party for any damages either direct, indirect, incidental, consequential or otherwise (including in each case,...
