Intended use of the product

EvaDrive in an add-on system to Handicare Eva Mobile lifts in order to provide a power assisted drive function to the rear
wheels. The EvaDrive system can either be delivered as an accessory to be retro-fitted to Eva450EE or Eva600EE, or as
a complete unit with the drive system fitted from the factory. The EvaDrive shall be used in the following situations and
environments:
• In a passive patient lift situation with a user in the lift, reducing the effort from the caregiver when
maneuvering the lift.
• In a dry environment and on a level surface.
• Home Care environments.
• Healthcare environments.
Assembly

Unpacking and inspection

The following is included in the EvaDrive package:
• Handlebar
• EvaDrive unit
• Allen key
• 2 screws + bracket for handlebar
The following is included in the EvaDrive battery package:
• Battery (Replaces the battery of Eva mobile lift)
• Charger
• Charger cable
Check to ensure that no components are left in the packaging.
Inspect the drive unit for signs of damage.
Periodic inspection must be performed at least once yearly. Use only original spare parts. Service and maintenance must
be performed according to instructions in the manual.
The drive unit must be charged for at least 10 hours before it is used for the first time.
Install the drive unit on the lift according to the accompanying assembly instructions. (Separate document) Assembly
must be performed by Handicare authorized personnel.
Installation of the handlebar
The handlebar must be installed on the mast at a height of at least 33.4 inch
from the floor. Measure from the lowest point of the handlebar.
The handlebar is secured using the accompanying Allen key.
SystemRoMedic
I N S T R U C T I O N S F O R U S E
TM
The complete Eva lift package with EvaDrive includes the following:
• Handlebar
• 2 screws + bracket for handlebar
33.4 inch/
850 mm
5
