Physio-Control
LIFEPAK CR2 AED
Trainer Manual
Get an original copy of the Physio-Control LIFEPAK CR2 AED
Trainer Operating Instructions for information on how to
operate and maintain your device.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIFEPAK CR2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Physio Control LIFEPAK CR2

Summary of Contents for Physio Control LIFEPAK CR2

  • Page 1 Physio-Control LIFEPAK CR2 AED Trainer Manual Get an original copy of the Physio-Control LIFEPAK CR2 AED Trainer Operating Instructions for information on how to operate and maintain your device.
  • Page 2 TRAINER...

  • Page 4: Table Of Contents

    Contents Getting Started Unpacking and Inspecting the Trainer ........5 Initial Setup ................5 Controls, Indicators, and Labels Outside Controls, Indicators, and Labels ........ 6 Inside Controls and Features ........... 8 Running the Default Scenario Entering Setup Mode Modifying Training Scenarios Setup Options Language List.................
  • Page 5 Software Updates Installing Software Updates ........... 32 Troubleshooting Tips for Software Updates ......35 Specifications Symbols...

  • Page 6: Getting Started

    Getting Started The LIFEPAK CR2 Trainer provides a way for trainees to practice responding to a simulated cardiac arrest event. The Trainer simulates the voice prompts and features of the LIFEPAK CR2 defibrillator, but does not deliver shocks. The Trainer is equipped with 2 preset training scenarios. These scenarios can be easily customized using the setup screen on the Trainer to provide a wide variety of training options.

  • Page 7: Controls, Indicators, And Labels

    Controls, Indicators, and Labels This section describes the controls, indicators, and labels on the device. Outside Controls, Indicators, and Labels ITEM FEATURE DESCRIPTION Latch To open the Trainer, insert your finger in the recessed area and pull up. Open the lid to turn the Trainer on.
  • Page 8 ITEM FEATURE DESCRIPTION Power indicator The green LED is off when the Trainer is turned off, and on when the Trainer is in use or in Setup mode. The LED turns to steady on when the lid is opened. When in Standby mode with the lid closed, the LED flashes once every 6 seconds.

  • Page 9: Inside Controls And Features

    Inside Controls and Features ITEM FEATURE DESCRIPTION button During training sessions, press the LANGUAGE LANGUAGE button, if prompted, to switch between your preset languages. button Press the button to turn the POWER POWER device on. Press and hold for at least 3 seconds to turn the device off.
  • Page 10 ITEM FEATURE DESCRIPTION During training sessions, press the CHILD MODE CHILD button button to switch between Adult MODE mode and Child mode. The green LED above the CHILD MODE button is illuminated when Child mode is selected. Note: The CHILD MODE button is disabled after the electrodes are placed on the manikin.
  • Page 11 Electrode Tray Features After the red handle is pulled, the electrodes are revealed as shown below. The training electrodes include a sensor that detects when the electrode pads are pressed onto a firm surface such as a manikin. During training sessions, this enables the Trainer to detect when the electrode pads have been placed and automatically continue the scenario.
  • Page 12 When the electrodes are unplugged and the Trainer lid is closed, the Trainer simulates a LIFEPAK CR2 defibrillator in which the electrode tray is not properly installed. The Power indicator turns off, and the Trainer beeps.

  • Page 13: Running The Default Scenario

    Running the Default Scenario To run the default scenario, follow these basic steps. Note: It is not necessary to turn the Trainer on before you begin. 1. Start with the lid closed. Open the lid to turn the Trainer on and begin the scenario.

  • Page 14: Entering Setup Mode

    Entering Setup Mode Setup Mode allows you to customize the two preset scenarios to meet your training needs. To access the setup screen and enter Setup Mode, remove the electrode tray as shown in the following illustrations. Note: Voice prompts will begin as soon as you open the lid. The voice prompts stop when you remove the electrode tray.
  • Page 15 When the electrode tray has been removed, the setup screen and buttons will be exposed as shown in the following illustration, and the setup screen will turn on automatically. If the Trainer is turned off, press the button to turn on the POWER setup screen.
  • Page 16 ITEM FEATURE DESCRIPTION Right Arrow button When the title at the top of the screen is highlighted ( MAIN MENU ), the right arrow moves SCENARIO X to the next screen. When a menu item within a screen is highlighted, the right arrow moves through the options for each menu item.

  • Page 17: Modifying Training Scenarios

    Modifying Training Scenarios The Trainer has two configurable training scenarios. To modify a training scenario, you must move from the Main Menu screen to the desired Scenario screen. 1. Starting in the Main Menu screen, press the DOWN buttons until is highlighted, and then press the MAIN MENU button until the desired scenario screen is displayed.

  • Page 18: Setup Options

    Note: If you close the lid with the Trainer turned on and the electrode tray out, the Power indicator turns off and the Trainer beeps to simulate a LIFEPAK CR2 defibrillator that is not ready for use. Each time you exit Setup mode, the settings you selected are saved until you change them again.
  • Page 19 MENU ITEM DESCRIPTION OPTIONS Volume Sets the audio volume. The 1, 2, 3, 4, 5, 6, 7, Auto Auto setting automatically adjusts the volume depending on surrounding noise levels. Battery Level Indicates the current battery High, Medium, Low level of the Trainer. See Replacing Batteries (on page 29) for more information.
  • Page 20 The following options appear in the setup screens. SCENARIO MENU ITEM DESCRIPTION OPTIONS Device Type Sets the Trainer to simulate Fully Automatic, either a fully automatic or Semi-automatic semi-automatic defibrillator. Note: A fully automatic defibrillator delivers a shock without requiring the user to press the SHOCK button.
  • Page 21 120 sec, 180 sec analyses. Note: The setting Short provides a shortened CPR interval. This setting is not available on the LIFEPAK CR2 defibrillator, but may be useful for demonstration purposes. cprINSIGHT During an actual cardiac arrest On, Off event, cprINSIGHT™ Analysis...
  • Page 22 DESCRIPTION OPTIONS No CPR During an actual cardiac arrest On, Off Detected event, the LIFEPAK CR2 defibrillator can detect whether CPR is being performed during CPR times. This setup option in the Trainer determines whether the Trainer will simulate a defibrillator that has not detected CPR.
  • Page 23 MENU ITEM DESCRIPTION OPTIONS Bilingual Determines whether the Trainer On, Off simulates a bilingual device. is selected, the Trainer will behave as though only one language is available. is selected, the Trainer will behave as though two languages are available. The voice prompts always begin with the primary language which was selected in the...

  • Page 24: Language List

    MENU ITEM DESCRIPTION OPTIONS Check Determines whether the trainee On, Off Breathing will be instructed to check for breathing before resuming CPR after a No Shock Advised decision. is selected, the trainee is not instructed to check for breathing before resuming CPR.

  • Page 25: Using The Trainer

    However, if you turn the Trainer on and then close the lid, the Power indicator will flash every 6 seconds to simulate a LIFEPAK CR2 defibrillator that is ready for use. Conduct the training session according to your local protocols.

  • Page 26: Simulating "Device Not Ready" Status

    3 seconds, or close the lid. POWER Simulating "Device Not Ready" Status The Trainer can simulate a LIFEPAK CR2 defibrillator that is not ready for use. 1. Remove the electrode tray or unplug the electrodes as shown in Electrode Tray Features (on page 10).

  • Page 27: Troubleshooting Tips

    Troubleshooting Tips This section explains problem conditions that you may encounter while using the Trainer. OBSERVATION CORRECTIVE ACTION Voice prompts don't start Confirm device is on and not paused when the lid is opened. (LED should be solid green). Close and re-open the lid. Press button for more than 3 POWER...
  • Page 28 OBSERVATION CORRECTIVE ACTION Text on setup screen is in Scroll down to second item in the an unfamiliar language. Main Menu and press button RIGHT until your language is visible. Press button to confirm selection CHECK and update text. Setup screen is black. The setup screen goes dark after 5 minutes of inactivity.

  • Page 29: Caring For The Trainer

    Caring for the Trainer Follow these instructions to keep the LIFEPAK CR2 Trainer in good working condition. Replacing Training Electrodes The reusable training electrodes can be used approximately 50 times. When the adhesive wears out, the electrodes should be replaced. You can order a set of 5 pairs of electrode pads, or a complete electrode tray.

  • Page 30: Replacing Batteries

    2. Insert the new pad into the connector and insert the pin. Ensure the connector is positioned so that the large- diameter recess for the head of the pin is at the front of the electrode, and the wire exits from the bottom of the electrode.

  • Page 31: Cleaning The Trainer

    IMPORTANT! For optimal performance, use Physio-Control replacement batteries. Alkaline batteries should always be used in the Trainer. Note: Be sure to replace all 4 D cell batteries at the same time with 4 new batteries. Cleaning the Trainer Clean the Trainer by wiping surfaces with one of the following: A lint-free, slightly damp cloth moistened with mild soap and water.

  • Page 32: Recycling Information

    Recycling Information Recycle the device and its accessories at the end of their useful life. Do not dispose of this product or its batteries in the unsorted municipal waste stream. Any batteries must be removed from the device and disposed of separately before disposing of the device.

  • Page 33: Accessories And Replacement Parts

    Training mat 11250-000144 Software Updates Software updates for the LIFEPAK CR2 Trainer may be released occasionally. To find out whether the software in your Trainer is up to date, first determine which software version is currently installed. Remove the electrode tray and turn on the Setup Screen.
  • Page 34 1. Insert the flash drive into the USB port on the bottom of the Trainer. 2. Turn on the Trainer, remove the electrode tray, and view the Setup Screen. Take note of the current software version displayed at the bottom of the Main Menu.
  • Page 35 should appear at the bottom of the Main Available Update Menu, followed by Scroll down to Update Now? Update . Use the button to select , and then press Now? RIGHT button. The screen will display CHECK Updating show the status as percent complete. Note: Software updates may take up to 15 minutes, depending on the type of update.
  • Page 36 Troubleshooting Tips for Software Updates This section explains problem conditions that you may encounter while updating the software. OBSERVATION CORRECTIVE ACTION Update Available message Ensure the flash drive is fully inserted. does not appear when the Ensure the battery level is High USB flash drive is inserted.
  • Page 37 Specifications CHARACTERISTIC DESCRIPTION General Device designed for low impact, low stress environments. For use in temperature- controlled areas protected from precipitation. Capable of withstanding heavy usage and prolonged periods of operation. Physical Height: 27.2 cm (10.7 in) with handle Characteristics Width: 21.8 cm (8.6 in) Depth: 8.6 cm (3.4 in) Weight: 1.8 kg (3.9 lb) with batteries...
  • Page 39 Physio-Control, Inc. 11811 Willows Road NE P.O. Box 97006 Redmond, WA 98073-9706 USA Tel 425.867.4000 Fax 425.867.4121 www.physio-control.com Physio-Control, Inc., 11811 Willows Road NE Redmond, WA 98052 Physio-Control Operations Netherlands B.V. Galjoenweg 68, 6222 NV Maastricht The Netherlands ©2016 Physio-Control, Inc. 3326581-000 All names herein are trademarks or registered trademarks of their respective owners.
