Generac Power Systems APS 6.0 Operating & Installation Manual page 31

ITEM PART NO.
1 0D5694
2 075475
3 022264
4 043180
5 0F3154
6 0C6070
7 0C4680
8 0C4647
9 0C4643
10 0D3973
11 0C6606
12 026073
13 0D3308
14 070728
15 0C5764
16 0C4643A
17 0C6066
18 0C5968
19 0C5759
20 0C5761
21 0C6069
22 0C6731
23 0C6067
24 0C4706
25 0C6068
26 0C5762
27 045764
28 0E3018
29 0A5735
30 0A5777
31 0E2567
32 0E2874
33 022145
34 022129
35 042907
36 0C5760E
37 0C5760D
Section 6 — Exploded Views and Parts Lists
QTY. DESCRIPTION
1 CASTING, TWIN REGULATOR HOUSING
4 SCREW PPHM M4-0.7 X 10mm
4 WASHER LOCK #8-M4
4 WASHER FLAT M4
1 SOLENOID COIL, 12VDC
1 SPRING-SOLENOID PLUNGER
1 PLUNGER LP REG. ASSY
1 GASKET, SOLENOID
1 INLET, TWIN REGULATOR NO HOLE
1 PLUG, EXPANSION 16MM TWINREG
1 BARBED STRAIGHT ½" I.D. HOSE X ½"NPT WITH VIBRA SEAL
2 PLUG STD PIPE 1/8 STEEL SQ HD
2 WASHER FLAT 3.2MM ID X 10MM OD
2 SCREW PFILHM M3-0.5 X 5
1 SPRING, REGULATOR 45N/M 32MM
1 INLET, TWIN REG 11.11 DIA.
1 SEAL, INLET REGULATOR
1 SUPPORT, INLET SEAL
1 PIN, PIVOT ARM
1 LEVER, REGULATOR
1 GASKET, DIAPHRAGM
1 RIVET .118 X .125 ALUMINUM
1 SUPPORT, DIAPHRAGM
1 DIAPHRAGM, TWIN REGULATOR
1 CAP, DIAPHRAGM SUPPORT
1 COVER,TWIN REGULATOR
8 SCREW HHTT M4-0.7 X 8 BP
1 GAS, INTAKE HOSE
1 BULK HEAD UNION
1 3/4" SEALING WASHER
1 BRACKET, REGULATOR SUPPORT
2 SCREW TAP-R 1/4"-20 X 3/4"
2 WASHER FLAT 5/16-M8
2 WASHER LOCK M8-5/16
2 SCREW HHC M8-1.25 X 16mm
1 JET INLET
1 JET INLET
Generac APS 6.0 DC Auxiliary Power Systems
Gas Valve Assembly - Drawing No. 0E2887-A
Generac ® Power Systems, Inc. 29
