Watt Drive L2000 Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INVERTER
L2000
Series
M A N U A L
NB596XA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L2000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Watt Drive L2000 Series

Summary of Contents for Watt Drive L2000 Series

  • Page 1 INVERTER L2000 Series M A N U A L NB596XA...
  • Page 2 L2000 frequency converters. It is recommended that this manual is read thoroughly before powering up the frequency converter for the first time. If any problem occurs, please contact your local distributors. WATT DRIVE Antriebstechnik GmbH is not responsible of the use of the frequency converters against the instructions.
  • Page 3 Manual WATT DRIVE WORLDWIDE WATT DRIVE Antriebstechnik GmbH A-2753 Markt Piesting Tel.: +43/2633/404-0 Fax: +43/2633/404-220 Wöllersdorferstraße 68 Internet: http:\\www.wattdrive.com e-mail: watt@wattdrive.com WATT DRIVE Nord GmbH D-59759 Arnsberg Tel.: +49/2932/9681-0 Fax: +49/2932/9681-81 e-mail: watt-arnsberg@t-online.de WATT DRIVE Süd GmbH D-72379 Hechingen Tel.: +49/7471/9685-0...
  • Page 4 Manual Please read this manual carefully before you install and operate an L2000 series inverter and observe all of the instructions given in there. This manual may also serve as a reference guide and therefore should always be kept at hand.
  • Page 5 Failure to observe this precaution could result in bodily injury. When using L2000 series inverters in EU countries, the EMC directive 89/336/EEC must be observed. To satisfy the EMC directive and to comply with the standard, the following provisions should be obeyed: A) Environmental conditions for the inverter: •...
  • Page 6 L2000 installation manual. D) Installation • For L2000 series inverters, the filters described hereafter have to be used and the installation notes have to be observed. If installed according to the following directions, the frequency inverters comply with the following...
  • Page 7 Manual Observe the following provisions for an electromagnetically compatible setup of your drive system: 1. As user you must ensure that the HF impedance between frequency inverter, filter and ground is as small as possible. • Take care it that the connections are metallic and have the largest possible areas (zink-plated mounting plates) 2.
  • Page 8 Manual Technical specifications and dimensions of L2000 foot print filter: Current at 40°C ambient temperature Overload 1.5 x I N for 10min WATT DRIVE POWER 55.0 Frequency 50 / 60 Hz STOP RESET FUNC. Material Steel, surface refined L2000 L2000...

  • Page 9: Table Of Contents

    Manual C O N T E N T S 1. SAFETY PRECAUTIONS ......................10 ..........................10 NSTALLATION ............................10 IRING ......................11 ONTROL AND OPERATION ..................... 12 AINTENANCE AND INSPECTION ............................12 THERS 2. INSPECTION UPON UNPACKING.................... 14 3. TECHNICAL SPECIFICATIONS....................15 4.

  • Page 10: Safety Precautions

    Safety precautions Safety precautions Installation The following safety precautions are to be observed when installing the frequency inverter: CAUTION Be sure to install the inverter on flame resistant material such as metal. Otherwise, there is a danger of fire. CAUTION Be shure not to place anything inflammable in the vicinity.

  • Page 11: Control And Operation

    Safety precautions CAUTION Remarks for using earth leakage circuit breakers in the mains supply: Frequency inverters with CE-filters (RFI-filter) and screened motor cables have a higher leakage current against earth. Especially in the moment of switching this can cause unintentional triggering of earth leakage circuit breakers. Because of the rectifier on the input side of the inverter there is the possibility to stall the switch-off function through amounts of DC current.

  • Page 12: Maintenance And Inspection

    Safety precautions CAUTION Check the following during and after the test run. Otherwise, there is a danger of machine breakage: Was the short cut bar between terminals +1 and + removed by mistake? Was the running direction of the motor correct? Was the inverter tripped during acceleration or deceleration? Were the indications of the rpm and the frequency meter correct? Were there any abnormal motor vibrations or noise?
  • Page 13 CAUTION PROTECTION AGAINST NOISE INTERFERENCE FROM THE INVERTER L2000 series inverters use many semiconductor switching elements such as transistors and IGBTs. For this reason, a radio set or measuring instrument located near the inverter is susceptible to noise interference. To protect the instruments from erreneous operation due to noise interference produced by the inverter, they should be installed well apart from the inverter.

  • Page 14: Inspection Upon Unpacking

    Manufacturing date MFG No. 78B T1128270005 Date: Tel.: +43/2633/404-0; e-mail: watt@wattdrive.com NE16452-2 In the illustration below, the contents of the model designation used for L2000 series inverters is explained: L2000 Version number ( , 1, 2 ...) Distribution for Inverter series...

  • Page 15: Technical Specifications

    Appearance and names of parts Technical specifications Inverter L 2 0 0 0 (200V series) Protective structure (Note 1) IP20 Overvoltage category Maximum motor size (4P) 0.55 0.75 in kW (Note 2) 230V 12.7 Maximum capacity in kVA 240V 13.3 Input supply phase 002 ~ 022NFE/U: Single phase / 3 phase 037 ~ 075LFU: 3 phase Rated input voltage...
  • Page 16 Appearance and names of parts Inverter L 2 0 0 0 (400V series) Protective structure (Note 1) IP20 Overvoltage category Maximum motor size (4P) 0.75 in kW (Note 2) Maximum capacity 460V 10.3 12.7 in kVA Input supply phase 004 ~ 075HF: 3 phase Rated input voltage 380VAC –10% ~ 460VAC +10% 50/60Hz +/-5%...
  • Page 17 Notes on technical specifications: Note 1: Protective structure is based upon EN60529 Note 2: The applicable motor is a WATT DRIVE standard four-pole motor. When using another motor, make sure that the rated motor current does not exceed the rated inverter current.
  • Page 18 Appearance and names of parts External dimensions and terminal positions of L2000 series inverters L2000 L2000 L2000 L2000 Legend: A Control terminals B Alarm terminals C Main terminals D Grounding terminals (All dimensions are in millimeters) Page 18 / 52...

  • Page 19: Appearance And Names Of Parts

    Appearance and names of parts Appearance and names of parts Digital operator Digital operator Key cover (can be opened) (can be opened) (Note 1) (Note 2) (Note 2) Key cover (Note 1) Screw Casing (Note 2) Serial interface Serial interface Casing Cooling fin Cooling fin...
  • Page 20 Appearance and names of parts digital operator Alarm Screw (can be opened) terminals (Note 2) (Note 2) Control terminals Key cover Rear cover Serial grounding (opened) interface terminal (PE) Mains circuit Casing terminals Cooling fin Alarm Digital operator terminals (can be opened) (Anm.2) Control terminals...

  • Page 21: Installation

    A more compact installation (back to back) may well be possible and should be discussed with WATT DRIVE. Please always leave enough room for the key cover to be opened without problems in order to connect wires to the control terminals.

  • Page 22: Wiring

    Wiring Wiring CAUTION Fasten the screws with the specified fastening torque so that they will not loosen unintentionally. Check all terminals for loose screws. Otherwise there is a danger of fire. CAUTION Use 60/75 deg C Cu wire or equivalent only. CAUTION Open type equipment CAUTION...

  • Page 23: Wiring The Control Terminals

    Wiring When connecting cables, the following details have to be considered: 1) Power supply cables must only be connected to the terminals L1, L2, and L3/N. 2) Do not connect any cables to the non-designated terminals in the upper terminal row (refer to figure above) as these terminals are reserved for L2000 internal purposes.

  • Page 24: General Remarks

    Wiring General remarks When connecting cables, the following items must be observed: When changing the power supply of the motor between the inverter and commercial power line, be sure to install mechanically interlocked switches (S1 and S2) as shown in the figure below: Earth leakage circuit breakers...
  • Page 25 Wiring Mains circuit power cable (L1, L2, L3(N), U, V, W, +1, +, - ) 90°-angle Signal line (H, O, OI, L, FM, 1, 2, 3, 4, 5, 11, 12, CM2, P24) Separate by 10cm or more Do not short circuit the terminals P24 and L, H, OI, or FM by mistake, because this may cause a malfunction.

  • Page 26: Wiring Equipment And Options

    Wiring Wiring equipment and options CAUTION Provide the wiring equipment in accordance with the safety codes required by jurisdictional authorities. If specified in standards or laws and regulations, follow their istructions. In the following table some guidelines for choosing an appropriate wire gauge are presented: Cable specifications Motor...
  • Page 27 Wiring Notes: Field wiring connections must be made by a UL listed and CSA certified closed-loop terminal connector sized for the wire gauge involved. The connector must be fixed using the crimp tool specified by the connector manufacturer. Only use a fuse that has the appropriate rated current. Be sure to use bigger wires for mains circuit cables and motor cables if the distance exceeds 20m.

  • Page 28: Terminals

    Wiring Terminals In the table below the location and dimensions of the power terminals (terminals for power supply and motor) are listed: Width in Location of power terminals Inverter model Screw size Width 002NFE M3,5 004NFE L3/N T1/U T2/V T3/W 007NFE~ View of power terminals...
  • Page 29 Wiring The following table shows the location and dimensions of all terminals: 007NFE~022NFE 002NFE, 004NFE Location of control terminals 075HFE 004HFE~040HFE 1 P24 Width Width Width L FM 12 11 Terminal type Screw Screw Screw Location of alarm terminals Power terminal M3.5 AL0 AL Control terminal...
  • Page 30 Wiring Terminal Symbol Purpose Initial setting Remarks categorie Reset input These inputs have different Input closed (ON): purposes depending on the user Multistage frequency Function active programmed configuration: input / USP function Input opened (OFF): Forward and reverse running Multistage frequency Digital Function not active command, up to 4 multistage...

  • Page 31: General Operation Notes

    T3 (W) L3 (N) “forward run“. 400V class: Three phase 380~460V Inverter 200V class: L2000 series Single phase 200~240V Three phase 200~240V Fault alarm signal Normal state: AL0-AL1 Trip and power off: AL0-AL2 Ground Page 31 / 52...
  • Page 32 General operating notes In order to test the inverter, follow the procedure described below: 1) Turn on power supply to the inverter. The power LED on the digital operator will light up. 2) Set function A 02 to 02. 3) Set function A 01 to 00. Now the inverter can be operated using the built in potentiometer which is indicated by the lit lamp above the potentiometer.

  • Page 33: Control Circuit Terminal Functions

    Control circuit terminal functions Control circuit terminal functions Overview Terminal Terminal function Description symbol Frequency Forward run Forward run (00) (Start/Stop) 1 P24 Reverse run Reverse run Input FW closed: Motor starts with forward running direction. (01) (Start/Stop) Input FW open: Motor decelerates from forward running. (same for reverse run using input RV) Inputs FW and RV both closed: motor decelerates.
  • Page 34 Control circuit terminal functions Terminal Terminal function Description symbol 24V DC common for Common terminal for the intelligent digital inputs digital inputs Set value configured Set value configured Set value configured 10V reference using potentiometer: using voltage input: using current input: voltage for analog set value (using potentiometer)

  • Page 35: Using The Digital Operator

    Using the digital operator The digital operator control panel The following figure shows the digital operator of an L2000 series inverter. The keys and displays (lamps and LED display) are shown with the names that are used throughout this manual:...
  • Page 36 Using the digital operator d 01 A -- A 01 FUNC FUNC (3 x) FUNC Turn Extended power on. function of A Group Frequency set value set by function F 01 (instead of analog input) Starting command via RUN key (instead of terminal FW/RV) Data is stored...

  • Page 37: Digital Operator Keys

    Using the digital operator Digital operator keys 58.1 After the data is changed, press the STR key to save data F 02 58.0 F 02 [UP key, DOWN key] ... These FUNC keys change parameter values. FUNC Pressing the FUNC key leaves data unchanged 57.9 FUNC...

  • Page 38: Basic Functions

    Using the digital operator Explanation of display after power on: When the inverter is turned on, the display returns to what was displayed when the power was last turned off (except in the extended function mode). Basic functions Standard Function Display * ) Function description / parameter setting range setting...
  • Page 39 Using the digital operator 100% Maximum A 04 frequency Base fre- Maximum quency frequency Standard Function Display * ) Function description / parameter setting range setting values Analog set value adjustment A 12 A 15 = 00 Analog input A 11 A 15 = 01 voltage or current set...
  • Page 40 DC braking L2000 series inverters have a configurable DC brake that is activated as soon as the stop command is issued. By applying a strobed DC voltage to the motor’s stator a braking torque is induced into the rotor that effectively works against the rotation of the motor.
  • Page 41 Using the digital operator DC brake The time during which the DC brake is activated can be A 55 braking time configured from 0.0s through 60s. Standard Function Display * ) Function description / parameter setting range setting values Upper/lower limiter, jump frequency Acceleration 1 Upper fre- quency limit...
  • Page 42 Using the digital operator Standard Function Display * ) Function description / parameter setting range setting values (Continued from previous page) control is not used, in this case it is really the set value that gets adjusted. So when the PID control is activated, the functions A 11 through A 14 do not adjust the set value but the actual value instead).
  • Page 43 Using the digital operator Standard Function Display * ) Function description / parameter setting range setting values Automatic Voltage Regulation (AVR) The AVR function causes motor voltage stabilization when DC voltage is fluctuating (e.g. due to an instable mains supply or a dropping or excessive DC voltage as a result of too short acceleration or deceleration times) and thus ensures a high torque (especially during acceleration).

  • Page 44: Extended Functions Of Groupb

    Electronic motor protection The L2000 series inverters have a an electronic facility that is able to monitor the driven motor’s thermal load. This electronic thermal motor protection facility is matched to the motor’s rated current using function b 12. However, the motor temperature can not be monitored if values are entered that are above the rated current of the motor.
  • Page 45 Using the digital operator Standard Function Display * ) Function description / parameter setting range setting values Overload restriction motor Overload limit b 23 b 23 Three different overload limit characteristics are available that can be chosen from: Overload limit 00: Overload limit is not active b 21 characteristic...
  • Page 46 Using the digital operator Standard Function Display * ) Function description / parameter setting range setting values Other functions The analog signal output on terminal FM (representing frequency Analog meter set value or output current) can be adjusted using this function. b 81 adjustment However, adjustment of the pulse signal (digital frequency set...

  • Page 47: Extended Functions Of Group C

    Using the digital operator Extended functions of group C The functions of group C are used for configuring the programmable digital inputs and outputs. Standard Function Display * ) Function description / parameter setting range setting values Programmable digital inputs Digital inputs 1, 2, 3, 4, and 5 can be assigned 15 different input functions.
  • Page 48 Using the digital operator Standard Function Display * ) Function description / parameter setting range setting values Programmable digital outputs Digital outputs can be assigned one of 6 different signalling functions. Both outputs may also be assigned to the same function. The outputs can be programmed either as normally closed contacts or as normally open contacts. One of the following signalling functions can be assigned: 00: RUN signal (signal active during motor run) 01: FA1 signal (frequency arrival)

  • Page 49: 10. Messages

    10. Messages Trip messages L2000 series inverters will trip on overcurrent, overvoltage and undervoltage to protect the inverter.The output is shut down and the motor runs free. This condition is held until the trip state is reset using the RESET key or the RS input.

  • Page 50: Other Messages

    Messages Other messages Cause Display The inverter is currently in standby mode There is an active reset signal. The mains power supply has been switched off. The waiting time prior to automatic inverter restart is coming to an end (refer to functions b 01 and b 03).

  • Page 51: Trouble Shooting

    Trouble shooting 11. Trouble shooting Error Condition Possible cause Remedy Does a voltage exist at the terminals L1, N (NFE models) or L1, L2 and L3 (HFE Check terminals L1, L2, L3 (U, V, W). models)? If this is the case, is the power Switch on the power supply afterwards.
  • Page 52 Trouble shooting Error Condition Possible cause Remedy Choose an inverter and motor of a higher rating. Are the motor load fluctuations too great? Reduce load fluctuations to a The motor run minimum. is unstable Avoid critical frequencies by using Are there motor resonating jump frequencies (A 63 –...

This manual is also suitable for:

L2000-002 nfeL2000-004 nfeL2000-005 nfeL2000-007 nfeL2000-011 nfeL2000-015 nfe ... Show all

Table of Contents
