Whirlpool GBD307PRB00 Parts Manual page 4

UPPER OVEN PARTS
For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00
(Designer White)
Illus.
No.
3
4
6
7
9
10
11
12
14
15
19
20
21
25
26
27
29
34
37
49
50
53
INSULATION
(Black) (S.Steel)
Part
No. DESCRIPTION
Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4448520 Bumper, Door
8302349 Divider, Vent
4449809 Screw
4455865 Top, Chassis
4449809 Screw
4452158 Tube, Vent
3196176 Screw
4452165 Lens, Light
4452368 Oven Light Assy
4452166 Bulb, Light
9759060 Frame, Front
4449040 Screw
4450118 Nut
4455382 Gasket, Door
4451478 Support, Insulation
4449809 Screw
4451605 Cap, Spacer
Rail, Side
8302793 Right Side
8302794 Left Side
4448444 Grommet
4449154 Screw
4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
4452234 Back, Chassis
4449809 Screw
Liner, Oven
(Not serviceable)
4455636 Sensor
4449154 Screw
4452267 Vent, Center
3400832 Screw
9759242 Thermostat (TOD)
(Temp.) SPST
4448933 Retainer, Gasket
4449154 Screw
4451747 Cover, Back
4449809 Screw
4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
4449316 Insulation, Wrap
4450365 Insulation, Back
4
(Biscuit)
8186315
