PRESTIGE Stand
Leg Kit Instructions
Kit Part Number:
Parts List
1. Leg Strut (2 pcs)
2. Short Strut (1 pc)
3. Gusset Assembly with T-Bolts (4 pcs)
4. LH Bracket (1 pc)
5. RH Bracket (1 pc)
6. T-Bolt Assembly (4 pcs)
7. End Cap (2 pcs)
8. Leveling Feet (4 pcs)
This Kit Requires the Prestige Wall Frame Assembly - Part
Number PSSTND02 Sold Separately
Recommended Tools:
- 1/2" Socket & Ratchet
- 3/4" Wrench
- Tape Measure
Dimensions (when assembled):
- 66" High
- 25 1/2" Wide
- 28 1/4" Deep
WARNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
WARNING
Failure to follow instructions below can
result in severe personal injury or damage if
ignored.
•
Instructions are for a qualified installer/
service technician.
•
Read all instructions before proceeding.
•
Follow instructions in proper order.
PSSTND03
Gusset Assembly
NOTICE
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
End Caps
T-Bolt
(2 each)
Gusset
Advertisement
Related Manuals for TriangleTube PSSTND03
Summary of Contents for TriangleTube PSSTND03
- Page 1 PRESTIGE Stand Leg Kit Instructions Kit Part Number: PSSTND03 Parts List 1. Leg Strut (2 pcs) 2. Short Strut (1 pc) 3. Gusset Assembly with T-Bolts (4 pcs) 4. LH Bracket (1 pc) 5. RH Bracket (1 pc) 6. T-Bolt Assembly (4 pcs) End Caps 7.
- Page 2 PRESTIGE Stand Leg Kit Instructions Wall Frame Assembly PSSTND02 Fig. 1: Prestige Leg Kit Components 1. Leg Strut (2 pcs) 5. RH Bracket (1 pc) 2. Short Strut (1 pc) 6. T-Bolt Assembly (4 pcs) 3. Gusset Assembly with T-Bolts (4 pcs) 7.
- Page 3 PRESTIGE Stand Leg Kit Instructions Leg Kit Assembly NOTICE 1. The installer must reference the kit instructions For ease of installation, it is best to lower the and have completed the assembly of the Wall T-Bolt and nut down in to the strut as shown in Figure 2.
- Page 4 PRESTIGE Stand Leg Kit Instructions 6. Place the long side of the Left and Right WARNING Brackets on the bottom of the Wall Frame Long Struts as shown in Figure 3. The short side of The position of the Gusset on the Leg Strut is each bracket should be flush with the bottom of critical to the stability of the Stand.
- Page 5 PRESTIGE Stand Leg Kit Instructions 12. Place the completed stand in the desired boiler Boiler Mounting location and adjust the feet as necessary to level the stand. Tighten the locknut on each foot 1. Ensure that all bolts are tight before mounting using a 3/4”...
