North Light JY-0088A-12W-W-PIR Manual

Bright PIR Solar Wall Light
Please read the entire instruction manual before use and save it for future reference. We reserve
the right for any errors in text or images and for making any necessary technical changes to this
document. If you should have any questions concerning technical problems please contact our
Customer Services.
Safety
• Avoid looking directly into the light source. Doing so may damage your eyesight.
• Only use the recommended type of rechargeable batteries.
• This product must not be modified or adapted in any way.
• Only let a qualified technician perform repairs and using only original spare parts.
• Do not let children play with the product.
• NEVER use non-rechargeable batteries in the light.
Installation
1. Drill 2 holes in the wall and mount the base-
plate and the arm. Use suitable screws for
the wall and wall plugs if necessary.
2. Attach the head of the light to the arm.
Operating instructions
1. Remove the diffuser from the light by
turning it anticlockwise.
2. Set the power switch to OFF and let
the light charge in the sunlight for 1–2 days
before use. Refit the diffuser.
3. Once the light has been charged, remove
the diffuser and set the power switch to
AUTO. Refit the diffuser.
GREAT BRITAIN • CUSTOMER SERVICE
tel. 0845 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Art.no 36-5558 Model JY-0088A-12W-W-PIR
Note: The light has two brightness settings:
• When it is dark outdisde, the light shines decoratively.
• When someone walks past the light within 2–3 m, the light shines even brighter for about
30 seconds before returning to the decorative lighting setting.
Care and maintenance
Clean the light using a soft, moist cloth. Use a mild detergent and never use solvents or strong,
abrasive cleaning agents for cleaning as these can damage the light. Set the power switch to
OFF before putting the light away for storage.
Troubleshooting guide
The wall light doesn't come on. • Make sure the power switch is in the AUTO position.
• The batteries are inserted incorrectly.
• The batteries are flat. Charge the batteries.
• The light does not come on in full daylight even if
The wall light comes on randomly. • Move the light to another place.
The light only shines for a short • See that the light is charged for at least 6 hours.
while at night.
The PIR sensor does not work. • Make sure that the sensor is directed towards
The light shines brightly despite it being • Move the light away from strong winds,
a while since anyone walked past.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.
Specifications
Number of LEDs 12
3000 K / 6000 K
Colour temperature
Detection zone Max 3 m within an angle of 90º
Protection class IP44
Diameter 34 cm
Operating temperature −10 to 45 ºC
English
the power switch is set to AUTO.
where people walk.
air conditioning units or air vents.
