North Light SXY81020CP-WW-P060 Instruction Manual

Solar String Light
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our
Customer Services.
Safety
• Handle the product with care, making sure not to damage
the surface of the solar cell and ensuring that it is not covered with
dust or affected by other contaminants.
• The product must not be changed or modified in any way.
• Do not let children play with the product.
Solar cell installation
In the ground
1. Set the switch on the back of the solar cell to ON.
2. Attach the ground spike to the solar cell and then push the spike
into the ground.
3. Adjust the solar cell in such a way that it can receive as much
sunlight as possible.
4. Place the string light in a suitable outdoor location.
5. The light comes on automatically at dusk (as long as the battery
has been charged).
UNITED KINGDOM • CUSTOMER SERVICE
Tel. 020 8247 9300 E-mail: customerservice@clasohlson.co.uk Internet: www.clasohlson.co.uk Postal: 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
Art.no 36-7551
On a structure, such as a wall
1. Detach the bracket from
the solar cell.
2. Using the bracket as a guide, mark
out the position of the mounting
holes on the wall or structure
onto which the solar cell is to be
fastened.
3. Use an appropriate type of screw
or fastener for the material of
the structure.
Ensure that there are no electrical wires or water pipes
concealed below the surface into which you intend to drill/screw.
4. Set the switch on the back of the solar cell to ON.
5. Fasten the solar cell back onto the bracket and adjust the angle of
the solar cell so it can receive as much sunlight as possible.
6. Place the string light in the desired outdoor location.
7. The light comes on automatically at dusk (as long as the battery
has been charged).
The string light can also be
powered by a battery pack (sold
separately) to enable it to be used
all year round. For battery pack
operation, unscrew the connector
on the cable joining the solar cell to
the string light and replace the solar
cell with a battery pack.
Care and maintenance
The string light and the solar cell can be cleaned by wiping them
carefully with a damp cloth. Use only mild cleaning agents, never
solvents or corrosive chemicals.
Model SXY81020CP-WW-P060
Replacing the battery in the solar cell:
1. Remove the 4 screws on the back of the solar cell.
Detach the back cover.
2. Replace the battery (1 × 14500 3.7 V 850 mAh Li-ion) making sure
that it is fitted with the correct polarity.
3. Refit the battery cover.
The battery must only be replaced with an equivalent rechargeable
battery.
Responsible disposal
This symbol indicates that this product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any
harm to the environment or health hazards caused
by incorrect waste disposal, the product must be
handed in for recycling so that the material can be
disposed of in a responsible manner. When recycling
your product, take it to your local collection facility or
contact the place of purchase. They will ensure that
the product is disposed of in an environmentally sound
manner.
Specifications
Rechargeable battery 1 × 14500 3.7 V 850 mAh Li-ion
Charging time Approx. 8 hours (in continuous sunlight)
Operating time Approx. 6 hours (when fully charged)
60 cm
5.4 m
ENGLISH
3.5 m
