C) Microscope - TOOLCRAFT LAB 5.0 Operating Instructions Manual

Digital microscope camera
Table of Contents

Advertisement

Available languages

Available languages

c) Microscope

A5
A6
A1
3.5" display
A2
MicroSD card slot
A3
Fine focus dial
A4
Object stage
A5
Coarse focus (unlock / lock)
A6
Battery indicator LED
A7
Image capture button
A8
5V/DC charging port
The rubber feet on the base of the microscope may leave marks on sensitive surfaces.
A1
A2
A3
A4
A7
A8 A9
A10
A9
A10 USB 2.0 Mini-B
A11 LED brightness adjust
A12 Digital zoom +/-
A13 Camera lens / LED light source
A14 Coarse focus (up / down)
A15 Battery compartment
A11
A12
A13
A15
AV-out television cable port
A14
