Software-specific information • OPC UA server • Description of the nodes of the information model
6.6.2.3.4 CalibrateTouch
Starts touch screen calibration. See arguments for the method call.
See also the description for
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:MethodSet/4:CalibrateTouch
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Control/4:CalibrateTouch
Arguments for method call
Argument Data type Name
0 UInt32 Timeout
6.6.2.3.5 LoadConfiguration
The Power Panel loads the last saved settings and restarts. Any changes made to the
and are lost.
Function identical to: Service page Save & Exit
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:MethodSet/4:LoadConfiguration
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Control/4:LoadConfiguration
Arguments for method call
Arguments
-
6.6.2.3.6 SaveConfiguration
Changes made to the parameters
settings on the Power Panel.
Function identical to: Service page Save & Exit
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:MethodSet/4:SaveConfiguration
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Control/4:SaveConfiguration
Arguments for method call
Arguments -
6.6.2.3.7 SetBrightness
Changes the screen brightness from 20% to 100%. See arguments for the method call.
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:MethodSet/4:SetBrightness
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Control/4:SetBrightness
Arguments for method call
Argument Data type Name
0 UInt32 Brightness
114
"Touch screen calibration" on page 52
Description
Touch screen calibration timeout in seconds.
Valid range: 1 - 300
→ Exit without saving (Button)
are saved. Method
→ Save changes (Button)
Description
Brightness in percent [%].
Range of values:
Scaling
Power Panel T30 User's manual V1.42 - Translation of the original documentation
in section Commissioning.
must be used to enable these stored
LoadConfiguration
0 - 100
0 → 20% to 100 → 100%
parameters are not saved
