B&R Power Panel T30 User Manual page 103

Software-specific information • OPC UA server • Description of the nodes of the information model
6.6.2.2.3 Network
Path to the object directory:
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Configuration/4:Network
ns BrowseName of the parameter
4 Hostname
NetworkMode
ActivateDNS
DNSSuffix
GetDNSFromDHCP
PrimaryDNS
SecondaryDNS
TertiaryDNS
IpAddress
SubnetMask
DefaultGateway
6.6.2.2.3.1 Hostname
Function identical to: Service page Network
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:ParameterSet/4:Hostname
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Configuration/4:Network/4:Hostname
Node attribute
NodeClass Variable
Datentyp String
AccessLevel CurrentRead, CurrentWrite
UserAccessLevel CurrentRead, CurrentWrite
6.6.2.2.3.2 NetworkMode
Function identical to: Service page Network
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/2:ParameterSet/4:NetworkMode
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT30/3:Configuration/4:Network/4:NetworkMode
Node attribute
NodeClass Variable
DataType BrNetMode (Enumeration)
AccessLevel CurrentRead, CurrentWrite
UserAccessLevel CurrentRead, CurrentWrite
Data type BrNetMode (enumeration)
Value String
0 DHCPClient
1 StaticIP
Power Panel T30 User's manual V1.42 - Translation of the original documentation
Description
Hostname of the Power Panel.
Network mode: DHCPClient or StaticIP.
Setting corresponds to option DHCP on service page Network.
Enable DNS usage.
DNS suffix for the fully qualified domain name (FQDN).
Enables/Disables obtaining IP addresses of the DNS servers from DHCP.
Address of the first DNS server.
Address of the second DNS server.
Address of the third DNS server.
Static IP address of the Power Panel.
Subnet mask.
IP address of the default gateway.
→ "Hostname" on page 59
→ "DHCP" on page 59
Service page R W
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
Network + +
103
