- Page 1 OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : WALL MOUNTED Indoor Unit Outdoor Unit D24AWN-ND11 R24AWN-UD11 www.lg.com P/NO : MFL57942736...
-
Page 2: Table Of Contents
Air Conditioner Ownerʼs Manual TABLE OF CONTENTS FOR YOUR RECORDS A. Safety Precautions ......3 B. Electrical Safety........6 Write the model and serial numbers here: Temporary Use of an Adapter ....6 Model # Temporary Use of an Extension Cord ...6 Serial # Symbols used in this Manual....6 You can find them on a label on the side of each unit. -
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. - Page 4 Safety Precautions • Improper or loose connections can cause heat generation or fire. Safely dispose off the packing materials. Like screws, nails, batteries, broken things etc after installation or svc and then tear away and throw away the plastic packaging bags. •...
- Page 5 Safety Precautions Always check for gas (refrigerant) leakage after installation or repair of product. • Low refrigerant levels may cause failure of product. Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a consumer air conditioner, not a precision refrigeration system.
-
Page 6: Electrical Safety
Electrical Safety Electrical Safety • This appliance must be properly grounded. To minimize the risk of electric shock, you must always plug into a grounded oulet. • Do not cut or remove the grounding prong from the power plug. • Attaching the adapter ground terminal to the wall receptacle cover screw does not ground the appliance unless the cover screw is metal and not insulated, and the wall receptacle is grounded through the house wiring. -
Page 7: Product Introduction
Product Introduction Product Introduction Here is a brief introduction of the indoor and outdoor units. Indoor Units Air inlet Grille tab Plasma filter (Optional) Front grille ON/OFF button Air filter Louvers Signal Air outlet (Vertical blades) receiver Flap (Horizontal blade) Operation Indication Lamps On/Off : Lights up during the system operation, error code and auto restart setting. -
Page 8: Operating Instructions
Operating Instructions Operating Instructions How to insert the Batteries 1. Remove the battery cover by pulling it according to the arrow direction. 2. Insert new batteries making sure that the (+) and (-) of battery are installed correctly. 3. Reattach the cover by sliding it back into position. NOTE 1. -
Page 9: Wireless Remote Controller
Operating Instructions Wireless Remote Controller Control Display Description panel screen Air circulation button*: Used to circulate the room air without cooling or Display heating. screen Sleep mode auto button*: Sets the sleep mode auto operation. Temperature adjustment buttons: Adjusts the room temperature when cooling and heating. -
Page 10: Basic Functions
Operating Instructions Basic functions 1. Cooling your room (Cooling operation) 1. Press to turn on the power. 2. Press repeatedly to select the cooling operation. - A is displayed on the display screen. 3. Press to set the desired temperature. - The temperature range is 18°C (64.4°F)- 30°C (80°F). - Page 11 Operating Instructions 4. Airing your room (Air Circulation operation) This mode only circulates the indoor air without changing the room temperature. The cooling lamp lights up in air circulation mode. Press to turn on the power. Fan button : Press / turn on the air circulation operation.
- Page 12 Operating Instructions 8. Setting the timer You can use the timer function to save energy and to use the air conditioner more efficiently. n Setting the current time Press p and hold it for longer than 3 seconds. - The AM/PM icon flickers at the bottom of the display screen. Press to select the times.
-
Page 13: Advanced Functions
Operating Instructions Advanced functions The air conditioner offers some additional advanced functions. 1. Changing room temperature quickly (Jet Cool) This mode allows you to cool indoor air quickly in summer or warm it quickly in winter. Press to turn on the power. Press COOL - In jet cooling mode, strong air blows out at a... - Page 14 Operating Instructions 3. Auto operation (Optional) (Artificial intelligence) Cooling-only models Code Description In this mode, the fan speed and the Cool temperature adjust automatically, based on Cool slightly the room temperature. Maintain Press to turn on the power. room temperature Press repeatedly to select auto Heat slightly...
- Page 15 Operating Instructions 5. °C/°F Conversion The unit converses from °C to °F or from °F to °C if Room Temperature KEY is pressed for 5 seconds. 6. Energy saving cooling mode This mode minimizes power consumption during cooling and increases the set temperature to the optimal level for a more comfortable environment.
-
Page 16: Operating The Air Conditioner Without The Remote Control
Operating Instructions Operating the air conditioner without the remote control You can use the On/Off button of the indoor unit to operate the air conditioner when the remote control is unavailable. However, the fan speed is set to high. 1. Open the front cover. - Lift up both sides of the cover slightly. -
Page 17: Restarting The Air Conditioner Automatically
Operating Instructions Restarting the air conditioner automatically When the air conditioner is turned on again after a power failure, this function restores the previous settings. This function is a factory default setting. Disabling auto restart 1. Open the front cover. - Lift up both sides of the cover slightly. -
Page 18: Forced Operation
Operating Instructions Forced operation Forced operation is used when the remote controller can't be used. The operation will be started if the ON/OFF button is pressed. If you want to stop the operation, re-press the button. ON/OFF button Heat pump Model Cooling Model Room Temp. -
Page 19: Maintenance And Service
Maintenance and Service Maintenance and Service Before performing any maintenance, turn off the main power to the system, disconnect the circuit breaker and unplug the power cord. Indoor Unit Clean the unit with a soft dry cloth. Do not use bleach or abrasives. Never use any of these •... -
Page 20: Outdoor Unit
Maintenance and Service Outdoor Unit The heat exchanger coils and panel vents of the outdoor unit should be checked regularly. If clogged with dirt or soot, the heat exchanger and panel vents may be professionally steam cleaned. NOTE Dirty or clogged coils will reduce the operating efficiency of the system and cause higher operating costs. Operation Tips! Do not overcool the room. -
Page 21: Troubleshooting Tips! Save Time And Money
Maintenance and Service Troubleshooting Tips! Save time and money! The air conditioner may be operating abnormally when: Problem Possible Causes What To Do n The air conditioner is • Make sure the air conditioner plug is pushed completely into the outlet. unplugged. - Page 22 22 Air Conditioner...
