Technical Specifications

• Power Supply:
Input: AC 100-240V, 50/60 Hz, 0.35A
• Frequency: 1MHz (±10%)
• Mode: 3 levels (Low, Medium, High)
• Time: 5, 10 or 15 minutes with auto turn off
• Power Output: (0.7W/cm
2 (Low), 1.0W/cm
• Duty Factor: 30% (Low), 40% (Medium), 50% (High)
• RBN : < 8.0
• Rated Output Power: 9.6W (±20%)
• Effective Intensity: 2.4W/cm (±20%)
2
• AER : 4 cm 2
• Beam Type: Collimated
• Modulation Wave Shape: Pulsed
• Operating Conditions:
Temperature: 5-40°C Humidity: 30-75%RH
GUIDANCE AND MANUFACTURER'S DECLARATION -
ELECTROMAGNETIC EMISSIONS FOR
ALL EQUIPMENT AND SYSTEMS
REVITIVE Ultrasound is intended for use in the electromagnetic
environment specified below. The user of REVITIVE Ultrasound should assure that it is
used in such an environment.
Emission test Compliance
RF emissions CISPR 11 Group 1
RF emissions CISPR 11 Class B
Harmonic
Class A
emissions IEC 61000-3-3
Voltage fluctuations/flicker
Complies
emissions IEC 61000-3-3
20
3269_IFU02_14269060.indd 20-21
Output: DC 15V, 1.2A
2 (Medium), 1.2W/cm 2 (High)
Air Pressure: 700-1060hPa
Electromagnetic environment –
guidance.
REVITIVE Ultrasound uses RF
energy only for its internal function.
Therefore, its RF emissions are very
low and are not likely to cause any
interference in nearby electronic
equipment.
REVITIVE Ultrasound is suitable for
use in all establishments, including
domestic establishments and those
directly connected to the public
low-voltage power supply network
that supplies buildings used for
domestic purposes.
Technical Specifications
RECOMMENDED SEPARATION DISTANCES
BETWEEN PORTABLE AND MOBILE RF
COMMUNICATIONS EQUIPMENT AND EQUIPMENT
OR SYSTEMS THAT ARE NOT LIFE SUPPORTING.
REVITIVE Ultrasound is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The user of REVITIVE Ultrasound can help prevent
electromagnetic interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and REVITIVE Ultrasound
as recommended below, according to the maximum output power of the
communications equipment.
Separation distance according to frequency of transmitter (m)
Rated
maximum
150 KHz to 80 80 MHz to 800
output power
MHz MHz
of transmitter
d= 3.5 d= 3.5
�P
(W)
V E
1
0.01 0.12 0.12
0.1 0.38 0.38
1 1.2 1.2
10 3.8 3.8
100 12 12
For transmitters rated at a maximum output power not listed above, the recommended
separation distance D in metres (M) can be estimated using the equation applicable to
the frequency of the transmitter, where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
800 MHz to 2.5 GHz
d= 7
�P
E
�P
1
1
0.23
0.73
2.3
7.3
23
