Installing the Scale Control Plus Meter
(for systems after October 2017)
1. Connecting the tap
1 2
Detach the tap's jack plug from the tank
and insert it into the jack plug socket of
the Scale Control Plus Meter.
2. Connecting the Scale Control
Plus Meter
Insert the jack plug of the Meter into the
socket closest to the centre on the top of
the Quooker tank.
3. Mounting the metal washer
Screw the washer provided into the
kitchen cabinet using the screw provided.
4. Securing the Scale Control Plus Meter
Mount the Meter on the metal washer
using the magnet on the back of the
3 4
Meter. Affix the sticker provided next to the
Meter on the inside of the cabinet.
