CMOSTEK CMT2281F2 User Manual

Hide thumbs Also See for CMT2281F2:
Table of Contents

Advertisement

Quick Links

Summary
CMT2281F2 is a low power, high performance OOK RF receiver chip.It covers a 300 MHz - 960MHz wireless
communication band with a RISC Flash type MCU embedded in it. It belongs to the CMOSTEK
NextGenRFTM series product.The product series include short range wireless communication chips, such as
transmitter, receiver, transceiver,SoC and so on.
The part numbers covered by this document are as shown below.
Part No.
CMT22181F2
Note：The test conditions for sensitivity and Rx current are at 433.92MHz, 1kbps, 0.1% BER
Copyright © By CMOSTEK
CMT2281F2 User Guide
Table1.
Part Numbers Covered by This Document
Frequency
Modem
300 MHz -
OOK
960MHz
Rx
Sensitivity
Current
-109dBm
4.5mA
Page 1/86
AN200
AN200
Configuration
Package
Embedded
SOP16
MCU
www.cmostek.com
