Summary of Contents for Ravelli APCF1
- Page 1 APCF1 Model Tripod www.Ravelliphoto.com...
- Page 2 Product Overview The Ravelli APCF1 is a Professional Quality Carbon Fiber Tripod providing a solid base for high-end photographic equipment. This model is a mix of carbon fiber and magnesium alloy making this tripod very light weight and incredibly durable. The removable ball head provides smooth adjustments to any angle and is equipped with a bubble level.
- Page 3 Identifying the parts...
-
Page 4: Height Adjustment
Using the Tripod Initial Set Up To begin using the tripod, open the carrying bag using the zipper and pull the tripod out of protective plastic bag. Your tripod is stored in the inverted position. Invert each leg and adjust the center column. Height Adjustment Adjusting the height of the tripod... - Page 5 The Quick Release Plate To remove the quick release plate, turn the quick release knob counter clockwise until it is fully rotated. Press the silver safety release button, and gently slide camera plate out. To attach the camera to the quick release plate, hold camera securely in one hand, and locate the...
- Page 6 Panning- For smooth consistent panning, tighten or loosen the ball head panning adjustment knob until the right amount of resistance is obtained. Turning the knob clockwise will tighten it and make panning slow and firmer. Turning the knob counter-clockwise to loosen it will make panning fast and easy.
- Page 7 center column shaft hole. You may have to rotate the column until you feel the tab align properly with the center column indention. Adjust the shaft until the right height is achieved then retighten the center column height adjustment knob to secure.
- Page 8 How to remove the head of the Tripod To remove the ball head from the legs, first ensure the pan adjustment knob is fully tightened. Next, grasp the ball head with one hand and the tripod legs with the other and rotate the ball head counter clockwise to unscrew it from the...
- Page 9 We also recommend purchasing sand bags or weights to set on the tripod legs to hold the tripod in place. Ravelli™ guarantees the tripod only and is not liable for damage caused to backdrops, cameras, lighting, or any other items.
-
Page 10: Specifications
Specifications Model: APCF1 Model Tripod Max Load: Supports Up To 17 LBS 360° Panning Angle: 180°, 90° Upward or 90° Downward Tilt Angle: Dimensions: Storage Height: 19” Collapsed Height: 18.5” Maximum Height: 65.75” Minimum Height: 19” (inverted height is 0) Weight: Tripod: 3.5 LBS... - Page 11 These dollies offer smooth movement with 3" rubber wheels and metal ball bearings. The Ravelli ATD also includes a one-step lock on each wheel to securely hold your tripod in place. The dolly is easily folded and has a carrying handle built in and includes a protective bag.
