- Page 1 DTNA 38N DTNA P3 instructions for use DTNA 38N-P3_(DC)_IM_20200902...
-
Page 3: Table Of Contents
FORM E HOW TO TEST AND REPLACE FAN ....................18 CHAPTER 3: HOW TO REPLACE AESTHETICAL PARTS ................20 PART 1: DOOR (DTNA 38N) ..........................21 3.2 PART 2: EVAPORATOR DOOR (DTNA 38N) ....................22 3.3 PART: HANDLE (DTNA 38N) ..........................23 3.4 PART 1: DOOR - (DTNA P3) ..........................24 3.5 PART: HANDLE - (DTNA P3) .......................... -
Page 4: Chapter 1: Instructions For Use
DTNA 38N-P3 CHAPTER 1 INSTRUCTIONS FOR USE DTNA 38N-P3_(DC)_IM_20200902... -
Page 5: General Information
All the models are extremely easy to install. They can work even if they are assembled at a slant of up to 30°. In order to make sure that your Indel B refrigerator works as efficiently as possible, please pay attention to the following general instructions: •... -
Page 6: Wiring System
DTNA 38N-P3 The refrigerators are pre-set for being assembled in a niche of the truck. It is very important for the refrigerating unit, consisting of the compressor and the condenser, to be well ventilated, with the cool air coming in from the bottom and going out from the top. You must ensure proper ventilation of the refrigerating unit. -
Page 7: Setting The Inside Temperature
This type of damage is considered to be non-warrantable. - DTNA Service Bulletins, pertaining to Indel B refrigerators, should be reviewed prior to replacing any components. - If nothing is running or only fan is running, using a volt meter on 20v DC setting, check voltage at fridge with truck off and fridge off . -
Page 8: Chapter 2: How To Detect Functional Problems And Fix Them
DTNA 38N-P3 CHAPTER 2 HOW TO DETECT FUNCTIONAL PROBLEMS AND FIX THEM DTNA 38N-P3_(DC)_IM_20200902... -
Page 9: Cooling/No Operations From Compressor And Fan
2.1 NO COOLING/NO OPERATIONS FROM COMPRESSOR AND FAN WARNING Before replacing the refrigerator, prior be sure that voltage is ok and trouble shooting steps described in these forms have been followed! Turn Cab Load Disconnect Switch to ON and Replace fuse. If fuse continues to Not ok check refrigerator fuse. -
Page 10: Cooling / Compressor And Fan Is Operating
DTNA 38N-P3 2.2 NO COOLING / COMPRESSOR AND FAN IS OPERATING WARNING Before replacing the refrigerator, prior be sure that voltage is ok and trouble shooting steps described in these forms have been followed! Check that thermostat is switched ON. -
Page 11: Form A How To Fix Lamp
2.3 FORM A HOW TO FIX LAMP The interior lighting is installed at the top. Check to make sure that a proper 12 V light bulb has been installed, based on the voltage of the electrical system to which the refrigerator has been connected. -
Page 12: Form B How To Short Circuit Thermostat On Ecu
DTNA 38N-P3 2.4 FORM B HOW TO SHORT CIRCUIT THERMOSTAT ON ECU Time: 3 minutes Disconnect the brown and the blue wire from ECU on positions C, P and T (1) Make a bridge between C and T (2) DTNA 38N-P3_(DC)_IM_20200902... -
Page 13: Form C How To Replace Thermostat
2.5 FORM C HOW TO REPLACE THERMOSTAT Time for repair: 35 minutes Remove the plastic rivet on the left of the lamp holder Unscrew evaporator from cabinet... - Page 14 DTNA 38N-P3 Unscrew the lamp holder (3 screws) Remove the thermostat knob pulling it out DTNA 38N-P3_(DC)_IM_20200902...
- Page 15 Unscrew the nut of the thermostat Disconnect the wires from thermostat...
- Page 16 DTNA 38N-P3 Unscrew the support of the thermostat Unscrew the fixing supports of the evaporator DTNA 38N-P3_(DC)_IM_20200902...
- Page 17 Pull out the support of the thermostat sensor Thermostat sensor support...
- Page 18 DTNA 38N-P3 Remove the rubber protection pipe DTNA 38N-P3_(DC)_IM_20200902...
-
Page 19: Form D How To Replace Ecu (Electronic Control Unit)
2.6 FORM D HOW TO REPLACE ECU (ELECTRONIC CONTROL UNIT) Time: 15 minutes Remove all the wires from the ECU Unscrew the ECU and remove it Remove the ECU connector from the compressor with the help of a screwdriver... -
Page 20: Form E How To Test And Replace Fan
DTNA 38N-P3 2.7 FORM E HOW TO TEST AND REPLACE FAN Time: 30 minutes Disconnect the wire from + and F Cut the plastic strip DTNA 38N-P3_(DC)_IM_20200902... - Page 21 Unscrew the fixing plastic bracket of the wires Unscrew the condenser support Cut the plastic strips of the fan to uninstall it...
-
Page 22: Chapter 3: How To Replace Aesthetical Parts
DTNA 38N-P3 CHAPTER 3 HOW TO REPLACE AESTHETICAL PARTS DTNA 38N-P3_(DC)_IM_20200902... -
Page 23: Part 1: Door (Dtna 38N)
3.1 PART 1: DOOR (DTNA 38N) Time: 10 minutes Unscrew the bottom hinge (3) Unscrew the top hinge and remove the door... -
Page 24: Part 2: Evaporator Door (Dtna 38N)
DTNA 38N-P3 3.2 PART 2: EVAPORATOR DOOR (DTNA 38N) Time: 5 minutes 1 open the evaporator door. 2 Bend the door using the two hands pushing from the sides 3 after the operation 2 pivots go out from the holes on the plastic frame... -
Page 25: Part: Handle (Dtna 38N)
3.3 PART: HANDLE (DTNA 38N) Time: 10 minutes 1 Raise up the handle and push the spring towards the middle. The handle and the pivot will be unfixed 2 Insert the pivot of the handle from the top of the door and push it inside. -
Page 26: Part 1: Door - (Dtna P3)
DTNA 38N-P3 3.4 PART 1: DOOR - (DTNA P3) Time: 10 minutes Unscrew the ventilation top grid (1) Unscrew the ventilation top grid (2) Unscrew the ventilation top grid (3) Unscrew the ventilation top grid (4) DTNA 38N-P3_(DC)_IM_20200902... - Page 27 Unscrew the top hinge Remove the door (1) Remove the door (2)
-
Page 28: Part: Handle - (Dtna P3)
DTNA 38N-P3 3.5 PART: HANDLE - (DTNA P3) Time: 10 minutes Unscrew the two frontal screws of the handle Unscrew the bottom of the handle Remove the bottom part of the handle Remove the handle DTNA 38N-P3_(DC)_IM_20200902... -
Page 29: Part 1: Door Panel - (Dtna P3)
3.6 PART 1: DOOR PANEL - (DTNA P3) Time: 12 minutes After having removed the handle, pull out the frame with the help of a screwdriver Keep out the bottom frame let slide the panel from the bottom... -
Page 30: Chapter 4: Spare Parts
DTNA 38N-P3 CHAPTER 4 SPARE PARTS DTNA 38N-P3_(DC)_IM_20200902... -
Page 32: Dtna 38N - Cabinet
DTNA 38N-P3 DTNA 38N - CABINET DTNA 38N-P3_(DC)_IM_20200902... -
Page 33: Dtna 38N - Cooling Unit
DTNA 38N - COOLING UNIT... -
Page 34: Dtna P3 - Cabinet
DTNA 38N-P3 DTNA P3 - CABINET DTNA 38N-P3_(DC)_IM_20200902... -
Page 35: Dtna P3 - Cooling Unit
DTNA P3 - COOLING UNIT... -
Page 36: Spare Parts List
DTNA 38N-P3 4.5 SPARE PARTS LIST Indel B p/n Description DTNA 38N DTNA P3 COMPRESSOR G524 G1366 L002 EVAPORATOR L003 CONDENSER L004 INNER SHELF Lower door big balcony without bottle dividers L006 Bottle retainer with dividers L007 Evaporator door L008...
