Laser Performance FUNBOAT Rigging Manual page 7

16. Fit the rudder assembly to the gudgeon plate.
(figure 16)
e rudder retaining clip locates the rudder
stock when the rudder assembly is positioned
on the gudgeon plate and should be adjusted
so that the stock cannot be removed without
depressing the clip by hand.
17. To put the rudder blade down from the fully
up position lift the tiller slightly and push
backwards. (figure 17)
18. e rudder assembly has a kick-up system
so that if you run aground the rudder will come
up automatically. is can be adjusted by reposi-
tioning the plastic bu er under the tiller. When
the rudder blade is fully down the tiller should
locate over the capstone on the stock.
If the rudder blade can be moved backwards
from the tip more than 3 mm then the plastic
bu er under the tiller should be moved
forward to remove the slack.
adjusted by loosening the Allen screws with
Allen key provided. Adjust to desired setting and
retention the screws. (figure 18)
Warning: e kick-up system is a safety feature in case
you run aground accidentally. Under normal circum-
stances the rudder should be lifted before approaching the
beach or slipway.
To lift the rudder raise the tiller slightly to
disengage the lock down mechanism and pull
the tiller towards you.
e bu er is
figure 16
figure 17
figure 18
