Laser Performance FUNBOAT Rigging Manual page 5

6. Attach the clew outhaul hook to the boom with the
clew tie down line using a reef knot. (figure 6)
7. Tie the clew outhaul to the fairlead on the outboard end
of the boom. read the clew outhaul through the hook
and back through the fairlead. Ensure that the outhaul is
threaded from right to left. (figure 7)
8. Take the outhaul forward and down the left hand side
of the boom. read the line through the fairlead on the
front end of the boom from left to right.
Attach one of the small sister clips to the end of the out-
haul with an over hand stop knot.
Attach the other sister clip to the outhaul shockcord and
join the two clips together. Attach the other end of the
shockcord to the outhaul hook. (figure 8)
9. Tie the cunningham line to the stainless steel D- ring
on the front of the sail.
through the lacing eye on the front of the mast. Tension
the cunningham line and tie o . (figure 9)
10. Clip the boom onto the lower mast above the
gooseneck plug. (figure 10)
11. Secure the clew hook onto the clew
of the sail. Tension the outhaul so that the clew tie
down is approximately 285 mm from the end of the boom.
is is a good place to start for medium conditions.
e stronger the wind, the more tension required on the
outhaul. Secure the outhaul line in the cleat. (figure 11)
read the cunningham line
figure 6
figure 7
figure 8
figure 9 figure 10
figure 11
285mm
