Laser Performance FUNBOAT Rigging Manual page 3

3. Identify all parts
1. Hull
2. Spar assembly
• Upper mast
• Lower mast
• Boom
3. Rudder assembly
4. Kicking strap block with cleat
5. Top kicker block
6. Mainsheet block with clip
7. Traveler block
8. Large sister clip
9. Small sister clip
Boom and
upper mast
Batten
set
Sister clip large
Traveller
Traveler strop
Mainsheet
Mainsheet block
Traveler block
Cunningham
Kicker block with
10. Clew hook
11. Mainsail
12. Rope kit code
• Mainsheet – 10 meters 8 mm
• Traveler – 1.64 meters 5 mm
• Traveler strop – 0.63 meters 5 mm
• Kicker line – 2.7 meters 6 mm
• Cunningham – 1.0 meter 4 mm
• Clew outhaul – 3.0 meters 4 mm
• Clew tie down – 0.35 meters 4 mm
• Outhaul shockcord – 1.12 meters 5 mm
Lower mast
Rudder
assembly
Kicker line
Top kicker block
hook
Mainsail
Sister clip small
Clew tie down
Clew outhaul
Clew hook
Clew shockcord
