Modulex MMP-080A/10B Installation Manual page 2

Installation Guide Lighting Fixture
MUSEUM platform / adjustable down light
MMP-080A/10B/DL/3
Installation Details Installation Diagram
Wiring connection
Please connect according to
the description of a power supply.
When connecting the driver,
careful attention should be
paid to connecting ＋ and −.
Metal part in a cable point,
please don't touch with bare
hand directly.
Optional parts installation
2
Turn around the body.
1
2 Pull out the body from the hood.
Turn around the option holder,
3
and put out .
4
Put a filter in hood.
5 Turn around the option holder,
and put in.
3
Please attention that
the sharpener lens is counted
UP to
two pieces of filter lenses.
3FILTERS
Donʼt put in the filters than
f
the rule number of pieces.
Causes of falling and damage.
Tilting angle setting
Please loose a screw by the
1
hexagonal wrench,and unrock.
Please regulate a point of view
2
to a scale.
Please use an attached hexagon
wrench by all means.
Caution
Wiring diagram
PE N L
(500mA MAX)
DC480mA
36.9V
L N PE + -
Driver
CAUTION！
Do not reverse polarity！
＋ RED
− BLACK
f
Body
OPTION
UP to 3FILTERS
HOLDER
1
Hood
OPTION
HOLDER
5
Sharpner
FILTER
lends
4
Inner HOOD
2
hexagonal wrench
1
Installation Details
Installation to ceiling
1 Install the safety wire to the
mounting frame.
+RED
Install the fixture to the mounting
2
frame.
-BLACK
LED
Make sure to install the safety wire
h
to the mounting frame securely.
Do not touch inner side of the body
with bare hands. Use clean soft
cloth to clean up and maintain
inner side of the body.
Make sure the fixture will not touch
any objects in ceiling.
The luminaire should be positioned
so that prolonged staring into the
luminaire at a distance closed than
5.2m is not expected.
Sharpner
lends
（Contact）
Concord Lighting
5/F, Longbow House,14-20 Chiswell Street, London, EC1Y 4TW, UK
Tel : +44-01273-616649
Installation Diagram
h
Safety wire
1
2 Ceiling
Mounting frame
Safety wire
Body
As you support edge of a main part,
.
please push it
※An inside glass filter is
not touched by hand .
（Manufacturer）
ModuleX Inc.
#21 AraiBldg, 1-20-6 Ebisu-Minami Shibuya-ku, Tokyo
Tel : +81-3-5768-3131
To install ModuleX safety
Caution
