- Page 1 Test Equipment Depot - 800.517.8431 - 5 Commonwealth Ave Woburn, MA 01801 - TestEquipmentDepot.com Rapid Red Cordless Stick Vacuum Manual Model: ACSV-1 22V, 200W Atrix...
- Page 2 Rapid Red Cordless Stick Vacuum Components 1. Motorized Illuminated Floor Brush 11. Dust release button 2. Floor Release button 12. Tool Holder 3. Crevice nozzle 13. Extension tube 4. Combo Tool 14. Battery Pack (x2) 5. Extension tube release button 15.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING-to reduce the risk of fire, electric shock, injury PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM. Never charge the battery or appliance for extended periods of time. Do not use this vacuum cleaner if the charger or battery are damaged. Do not use this product without the dust container and filter in place. - Page 4 ACCESSORIES Extension Tube: Use for extended reach when using as an upright unit or for hard to reach places. Motorized Illuminated Floor Brush: Use this for hard floors and tight knit rugs and carpets. Easily picks up dirt dust and small debris. Motorized Upholstery Nozzle: Use this for upholstery, stairs, vehicles etc.
- Page 5 2. Install the dust container by inserting the clip into the main body, then put the upper side into place. It will "click" to secure. Assemble motorized illuminated floor brush: 1. Insert the connector of the motorized illuminated floor brush into the base of the extension tube by clicking it into place.
-
Page 7: Before First Use
3. If using accessories without the extension tube, simply attach them to the main body. It will "click" when secure. BEFORE FIRST USE 1. Hang the vacuum unit on the wall mount to ensure the vacuum is placed high enough for the vacuum to be securely mounted. 2. -
Page 8: Battery Charging
Battery Charging 1. Push the release button and take the battery module out. Plug the cable into the power inlet located on the side of the battery. When charging, the indicator light will be illuminated RED. Once fully charged this indicator light will turn Blue. -
Page 9: Operating The Vacuum
OPERATING THE VACUUM CAUTION: The vacuum must be fully charged before using for the first time. 1. Remove the vacuum cleaner from the wall mount. If using as a hand- held unit, remove the extension tube and attach the desired accessory. 2. -
Page 10: Cleaning The Filter
Cleaning the filter: 1. Remove the dust container from the main body. 2. Twist counterclockwise to remove the filter cover. 3. Lift to remove the microfiber filter. 4. Rinse the filters thoroughly under cold water. Do not use soap or other cleaning solvents. -
Page 11: Cleaning The Brush Roller
Cleaning the brush roller: 1. Remove the brush roller from the brush housing. Slide the brush roller fastener (A) away from the brush as below. 2. Carefully clean and remove the hair and debris from the brush roller. Wipe to clean only, do not use any soap or harsh cleaning solvents. -
Page 12: Troubleshooting
TROUBLESHOOTING The vacuum will not power on. This may be caused by a dead battery. This can occur if the vacuum has been used or stored for an extended period of time. Connect the vacuum to the charger and allow for a full charging cycle to complete. The vacuum stopped suddenly: This will occur if the safety/ thermal cut-out device has been activated. - Page 13 Input Voltage - Charger 100-240V 50/60Hz Operating Voltage Operating Power 200W Floor Brush Power Battery Capacity 2200mAh Charging Time 2 Hours Dust Bin Capacity 2 Quart DISPOSAL This vacuum cleaner is supplied with a lithium-ion battery. This must be disposed of properly, in accordance to your local laws and ordinances. Test Equipment Depot - 800.517.8431 - 5 Commonwealth Ave Woburn, MA 01801 - TestEquipmentDepot.com...
-
Page 14: Warranty Information
Atrix Rapid Red Stick Vacuum Limited Warranty: To the original user purchasing the Atrix Rapid Red Stick Vacuum, Atrix warrants that the vacuum will be free of defects in material and manufacture for a period of one (1) year from the date of purchase.
