INDEX INDEX PAGE Table Of Contents/Company Information Strobe System Requirements ENGINEERING COMPANY, INC. Aircraft not specifically mentioned on the eligibility list 51 WINTHROP ROAD, CHESTER, CT 06412-0684 ● PHONE: (860) 526-9504 FAX: (860) 526-2009 Strobe System Wiring Strobe Power Supply Installation Makers of Aviation, Automotive and Industrial Safety Lighting since 1953 Orion 500 LED Light Assemblies...
AIRCRAFT NOT SPECIFICALLY MENTIONED ON THE ELIGIBILITY LIST ESTABLISHING SOLID ANGLE BLOCKAGE WITH REFERENCE TO AC ANTI-COLLISION LIGHT INSTALLATION PROCEDURES 43.13-2A, CHAPTER 4. STC SA800EA / STC SA615EA / STC SA21NE 1. To determine the vertical angles to use with reference to Figure 7 The following information is to assist in the installation of a custom and 8 of the aforementioned chapter 4, attach a long string to the Whelen anti-collision strobe light system on any aircraft, and how to...
STROBE POWER SUPPLY INSTALLATION INSTALLATION PROCEDURES: Wiring WARNING!!! STROBE LIGHT POWER SUPPLIES ARE Location POLARITY SENSITIVE. REVERSING THE INPUT POLARITY WILL CAUSE SEVERE DAMAGE TO THE 1. Consider areas or locations designated by the aircraft man- POWER SUPPLY! ufacturer. Do not mount the strobe power supply closer than three (3) feet of the ADF loop.
ORION 500 LED LIGHT ASSEMBLIES MODEL OR5001V & OR5002V LED Tail Position /Anti-Collision Lighthead Assembly All LED self-contained tail mounted Position/Anti-Collision system. Eliminates the need for external power supplies and reduces current draw and provides thousands of hours of operation.
Page 8
Lens, Model 90667 (No Drain Slot, Hardcoat) * For shipping purposes only 38-0131364-00 Gasket, VHB Seal 01-0290717-00 Sub-Assy, ORION-500, Model OR5001V (12 VDC) 13-040130-040 Nut, #4-40 X 1/4, Hex Brass ORION Model OR5002V 28V Series Exploded View Parts Figure 8b...
Page 10
Model OR6501G, OR6501R 14V Series Model OR6502G, OR6502R 28V Series Exploded View Parts Exploded View Parts Figure 10a Figure 10b Lens P/N 01-0251094-00 Shown For ReferenceOnly Drain Hole Drain Hole Model OR6501G & OR6501R Series Parts List Model OR6502G & OR6502R Series Parts List ITEM PART NUMBER DESCRIPTION...
Page 12
Model OR6501GE, OR6501RE 12V Series Exploded View Parts Figure 12a Model OR6501GE, OR6501RE Series Parts List ITEM PART NUMBER DESCRIPTION — 01-0790701-01 OR6501GE Wingtip Position/Anti-Collision Light, 12V (Green) — 01-0790701-02 OR6501RE Wingtip Position/Anti-Collision Light, 12V (Red) 07-771790-100 Mounting Plate, Model 90701 (Heli-Coils, CMPL) —...
LED LIGHT ASSEMBLIES MODEL 90520 ( ) SERIES LED FLASHING BEACON (Red & White LED’s) TSO-C96a CLASS III APPROVED 90520 series LED beacons are FAA TSO compliant self-contained LED anti-collision lights (Ref. Class III - 100 effective candlepower). They are designed to replace strobe lightheads as small as the A470A with available models to replace HR self-contained beacons (HRCFA) or our legacy 70900 LED beacon.
LED LIGHT ASSEMBLIES MODEL 71080 ( ) SERIES LED BEACON (Red LED’s) LED Flashing Anti-Collision Light Assembly (150 eff. Cd) (14 VDC & 28 VDC) Anti-Collision 71080 series LED beacons are FAA TSO compliant Self-Contained LED lights (Ref. Class I - 150 effective candlepower). They are designed to replace a range of products. Refer to models and descriptions below.
SELF CONTAINED LIGHT ASSEMBLIES TSO-C96a CLASS III MODEL 70900 ( ) SERIES APPROVED FLASHING ANTI-COLLISION LIGHT ASSEMBLY 70900 series are FAA TSO compliant self-contained anti-collision lights for fixed wing aircraft. An external power unit is not required. Conservative lab life results greater than 20,000 hours. No EMI or RFI produced. All units meet the minimum requirements stated in FAR Parts 23 &...
SELF CONTAINED LIGHT ASSEMBLIES MODEL 71055 ( ) SERIES LED BEACON ANTI-COLLISION LIGHT ASSEMBLY TSO-C96a CLASS III APPROVED 71055 series beacons are FAA TSO compliant self-contained LED Anti-Collision lights. They are designed to replace existing quartz halogen flasher beacons installed as original equipment on single engine Cessna's from 1967 and later (contact factory for details).
Page 32
MODEL HRCFA SERIES SELF-CONTAINED STROBE ANTI-COLLISION LIGHT ASSEMBLY ® HRCFA series is a self-contained CometFlash strobe Anti-Collision light. The unique polycarbonate optic lens and reflector design re-directs stray light rays into the horizontal plane to provide maximum 360º of uniform light coverage. Available in three different lens colors, aviation Red, aviation White and split aviation Red/White and in radio-shielded configurations.
Page 34
STROBE LIGHTHEAD ASSEMBLIES MODEL A470A SERIES A470A series remote strobe light assembly is compatible with all Whelen power supplies. It can be installed on the fuselage or the vertical fin. The unique polycarbonate optic lens and reflector design, re-directs stray light rays into the horizontal plane to provide the maximum 360º...
Page 36
MODEL A650PG/PR SERIES WINGTIP STROBE ANTI-COLLISION/POSITION LIGHT ASSEMBLY A650 PG/PR Series wingtip with Anti-Collision & Forward Position lights can be used to convert non-Whelen Position lights into a Position/Anti- Collision light system. The small size allows for mounting into a wing tip enclosure.
LED LIGHT ASSEMBLIES 71110 ( ) SERIES WING TIP LED FORWARD POSITION LIGHT STROBE ASSEMBLY 71110 series is a wing tip mounted strobe anti-collision/position light assembly utilizing LED’s for the forward position lights. The LED’s pro- vide a significant reduction in current draw over conventional position light bulbs.
Page 40
INSTALLATION OF MODEL A612 with an A610 Flash Tube A612 glass lens and A610 flash tube are used for installing wing tip strobes in single engine Cessna’s 1972 and later. The existing position light retainer is modified to accommodate the lens, and the flash tube is mounted directly behind.
Page 42
MODEL A500A SERIES INSTALLATION A500A Series Combination Strobe/Tail Navigation light used when the wingtip Anti-Collision lights are mounted in an enclosure and can’t provide 360º of strobe coverage. It is a direct replacement for the standard Tail Position light. Available in a radio-shielded version. Voltage (14 or 28) and mounting (hori- VERTICAL HORIZONTAL zontal or vertical) must be specified when ordering.
LED LIGHT ASSEMBLIES MODEL 71011 ( ) SERIES LED TAIL POSITION LIGHT ASSEMBLY 71011 series are LED tail position lights designed to replace the existing “old style” tail lights typically seen mounted on most general aviation, corporate, and helicopter applications. They have all the advantages associated with using LED’s as a light source, improved reliability, and reduced operating costs and are available with horizontal or vertical mounts with 14 Volt or 28 Volt versions.
LED LIGHT ASSEMBLIES MODEL 71554 ( ) SERIES LED TAIL POSITION LIGHT ASSEMBLY 71554 Series in our newest LED Tail Position Light. Exact Footprint for Whelen Models A555A and 71011 Taillights. Available in horizontal or vertical mount. TSO-C30c TYPE III SO C APPROVED Model 71554( ) Specifications...
MODEL A600 PG/PR SERIES INSTALLATION A600 PG/PR series wing tip anti-collision, forward position and tail tail position lights, all in one compact unit. Tail position light eliminates the need for a tail mounted position light. Available in 14 or 28 VDC and in a radio-shielded version.
MODEL A650 SERIES INSTALLATION A650 series converts W1285 position lights into a position/anti-collision system by removing the existing retainer & replacing it with the A650 assembly. Radio-shielded version available. Model A650 Specifications Model Part Exposed Description Color Approvals Weight Numbers Number Height A650...
CONTINUED AIRWORTHINESS FLOW CHART Inspect Lens Excessive scratches, Replace Lens discolorations or cracking? Check Lens Mounting Loose or Tighten or missing Replace hardware? Check Operation Improper Check wiring Operation? and connections Refer to trouble-shooting procedures for strobe lights Complete Document #05131 Rev. D The document reference is online, please check the correspondence between the online documentation and the printed version.
Page 54
If noise problems persist, and the procedures described have not ground circuit. Alternator, electrical motor, fuel pumps and strobe light cleared them up, please contact the Whelen Engineering Company for power supplies draw heavy current through the ground circuit of the assistance.
Page 58
NOTES Document #05131 Rev. D The document reference is online, please check the correspondence between the online documentation and the printed version.
