Phone: (860) 526-9504
Internet: www.flyWAT.com
Sales/Service e-mail: info@flyWAT.com
WARNING: This product can expose you to chemicals including Methylene Chloride which is known to the State of California to cause cancer, and
Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
MODEL LIST
Model
P36P1L
P36P1T
P36P2L
P36P2T
P46P1L
P46P2L
*NOMINAL
INSTALLATION PROCEDURES: The following information
provides guidelines for the installation of the WAT LED PAR
Lights listed above. Please refer to the OEM manual for
your
aircraft
for
specific
instructions.
1.
Choose the appropriate replacement light assembly.
Note: It is not required to change all PAR lights or Taxi
lights to the new LED PAR lights.
2.
Place the lighting switch in the OFF position.
3.
Inspect the housing, attachment points and retainer for
any signs of abnormal wear or damage.
4.
Loosen or remove the hardware holding the lamp in
place. Take steps to ensure the retainer doesn't fall
from the lamp assembly before it is ready to be
removed.
5.
Place retainer screws in a safe place.
6.
Remove the lamp from the holder.
7.
Note there are two wires connected to the (existing)
lamp. Using a multi-meter, identify the negative wire by
measuring continuity to ground. Place a piece of black
electrical tape around the wire identified as ground.
This is your negative lead.
8.
Identify the positive wire as the remaining wire lead.
The LED light assembly is polarity sensitive, however
you will not damage the unit by reversing the polarity.
9.
While holding the lamp, loosen the screws holding the
attached wires. Remove each wire from the lamp.
©2014 Whelen Aerospace Technologies
Form No. 14793D (032719)
Part #
Style
01-0771833-10
PAR36
01-0771833-15
PAR36
01-0771833-20
PAR36
01-0771833-25
PAR36
01-0790750-10
PAR46
01-0790750-20
PAR46
removal
and
installation
Page 1
Application
Weight*
Landing
0.52 lbs.
Taxi
0.52 lbs.
Landing
0.52 lbs.
Taxi
0.52 lbs.
Landing
1.00 lbs.
Landing
1.00 lbs.
10. Secure the LED Light, note the terminal markings for
positive and negative, attach the negative marked wire
to the negative side terminal post of the LED Light.
11. Attach the positive wire to the positive side terminal
post. Remove tape or temporary placard which
identified the polarity of the wiring inside the housing.
12. If required, install the rubber gasket included with your
new LED Light around the LED Light assembly. A light
application of a common hand soap on the rubber may
aid in its fit into the light housing.
13. Place the LED light into the housing ensuring the key
(of the assembly) matches the key of the housing.
Proper orientation of the lamp is necessary for beam
orientation to be left and right of centerline while in
operation. For a Taxi light, the 'lines' of the inner optic
should be orientated vertically to produce a horizontal
light beam.
14. Secure the retainer. Care should be taken to tighten the
screw only to the point the retainer does not turn with
hand pressure. Over-tightening may stress the
polycarbonate lens of the LED Light.
15. Place the light switch in the ON position and verify
proper operation of the WAT LED lamp.
16. Determine that the Landing or Taxi light characteristics
have not been substantially affected, per 14CFR
23.1383.
17. If required, update aircraft records utilizing FAA Field
Approval (Form 337) or equivalent.
STC Manual
Installation Guide/ICA
VDC*
Input Current*
14VDC
1.36 Amps
14VDC
1.36 Amps
28VDC
0.68 Amps
28VDC
0.68 Amps
14VDC
2.60 Amps
28VDC
1.25 Amps

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAT P36P1L and is the answer not in the manual?

Questions and answers

Summary of Contents for Whelen Engineering Company WAT P36P1L

  • Page 1 Phone: (860) 526-9504 STC Manual Internet: www.flyWAT.com Installation Guide/ICA Sales/Service e-mail: info@flyWAT.com WARNING: This product can expose you to chemicals including Methylene Chloride which is known to the State of California to cause cancer, and Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
  • Page 2 Polarity shown on label +14V flyWAT www. .com Alignment +VDC GROUND Note - The ground terminal is electrically isolated from the case. PAR46 (reference-only) Polarity shown on label +14V Alignment flyWAT www. .com +VDC GROUND Note - The ground terminal is electrically isolated from the case.
  • Page 3 AIRWORTHINESS LIMITATIONS: The Airworthiness Limitations section is FAA approved and specifies inspections and other maintenance required under §43.16 and §91.403 of the Federal Aviation Regulations, unless an alternative program has been approved. No airworthiness limitations are associated with the installation of the light assembly. No airworthiness limitations are associated with the installation of the LED Taxi and Landing Lights.
  • Page 4 Wiring Diagram flyWAT +14V www. .com Existing Existing Aircraft Ground (+) VDC Wire Existing Existing Landing/Taxi Light Fuse or Switch Circuit Breaker TROUBLESHOOTING PROCEDURE: The following information is to provide guidelines for troubleshooting the LED Light Models listed on page 1. Note: A circuit feature of the Parmetheus Plus is multiple parallel paths of LEDs and fixed current sources.
  • Page 5 REPLACEMENT PARTS: PAR36 (All Models) ITEM PART NUMBER DESCRIPTION 6 8 - 3 9 7 1 4 8 6 A 3 0 LENS, CLEAR NON OPTIC PAR-36 1 5 - 0 4 5 2 1 6 - 0 6 8 SCREW, 4 X 3/8 PFH PLASTI-LOC SS W/NYSEAL 1 4 - 0 8 2 2 0 2 - 0 4 1 SCREW, 8-32 X 1/4 PH SLOT, BRASS, TERMINAL (NOT SHOWN)
