ASSEMBLY INSTRUCTIONS
TYPHOON GAMING HIGH BACK CHAIR
JBSTEALBK/JBSTEALBL/JBSTEALRD/JBSTEALWH
Weight capacity: 120kgs
This design and instruction booklet is subject to copyright.
www.officeworks.com.au
1CTN
For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au
1/11
Advertisement
Related Manuals for J.Burrows TYPHOON JBSTEALBK
Summary of Contents for J.Burrows TYPHOON JBSTEALBK
- Page 1 ASSEMBLY INSTRUCTIONS TYPHOON GAMING HIGH BACK CHAIR JBSTEALBK/JBSTEALBL/JBSTEALRD/JBSTEALWH Weight capacity: 120kgs This design and instruction booklet is subject to copyright. www.officeworks.com.au 1CTN For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au 1/11...
- Page 2 Assembly Video • To view an assembly video, go to https://www.officeworks.com.au • Search the product by item code or name: • Click on the icon to watch the video. (03) 9310 3011 NOTE • Please check you have all hardware before assembly. •...
- Page 3 H-L / H-R (M8x22mm) (M5 x 10mm) x 16 3/11...
- Page 4 Note:Turn the Star Base (B) upside down. Push the Castors (A) firmly into hole at the end of each leg. Turn the Star Base (B) upright and insert Gas Lift (C) into the center hole of Star Base (B). Place cover (D) over the Gas Lift (C). 4 Pcs M8x22mm Bolt used to complete...
- Page 5 4 Pcs M8x22mm Bolt used to complete this step. Note: Align the Seat Plate (E) so the FRONT of the Seat Plate matches the FRONT label on the bottom of the Seat Cushion (G). Tighten the screws with Allen Key (T). 4 Pcs M8x22mm Bolt used to complete...
- Page 6 Warning : DO NOT adjust/ touch the backrest lever before the backrest has been securely fastened to bracket. Doing so will cause the bracket to spring forward and may Bracket Bracket Recline Lever cause harm. Keep hands clear of the recline mechanism until the backrest has been assembled.
- Page 7 2 Pcs M8x22mm Bolt used to complete this step. Note: Using 2 x Screws (Q) through lower holes of Bracket to attach Back cushion (F). Tighten the screws. 2 Pcs M5x10mm Bolt used to complete this step. Note: Place the Plastic Cover (M) on the upper Angle Adjuster (I) using 2 x Screws (R) with Allen Key (T).
- Page 8 Note: Press the Plastic Caps (S) into the Plastic Cover to cover the screws. Note: Place assembled Seat Cushion (G) on the Gas Lift (C). Push down firmly until connection is secure. 8/11...
- Page 9 Note: Headrest cushion - Place the strap through the holes at the top of the backrest. Fasten the clips by pushing together. Lumbar cushion – Place the bottom straps through the gap between the seat and back rest. Feed the top straps through the holes at the top of the backrest. Fasten the clips by pushing together. Your Typhoon Gaming High Back Chair is now complete and ready for use.
-
Page 10: Care Instructions
Care Instructions • Wipe with a damp cloth and mild soap. Wipe dry immediately with an absorbent dry cloth. • Treat spills immediately with an absorbent cloth by blotting the spill. • Do not use detergents, solvents or abrasive cleaners. •... - Page 11 TYPHOON GAMING HIGH BACK CHAIR Functionality Arm Height Adjust - Pull lever up whilst moving the arm up or down. Release lever at desired height. Back Tilt - Sitting in the chair pull the lever up. Move your upper body fore and aft to a comfortable position.
