11. Disposal

The AdaptDx Pro includes electronics, display screens, batteries and other components that may release
toxic materials into the environment with improper disposal. Disposal of the AdaptDx Pro should be in
accordance with applicable state and local laws for the disposal of electronic equipment.

12. Specifications

Photobleaching Subsystem
• Mechanism: flash
• Bleaching Wavelength: 505 nm
• Bleaching Intensity: 76% effective bleach
Stimulus Subsystem
• Stimulus Wavelength: 505 nm
• Stimulus Duration: 200 msec
• Stimulus Size: 2°-diameter
• Stimulus Location: 5° inferior to the fixation light
• Maximum Stimulus Intensity: 20.9 scot mlx
• Dynamic Range of Stimulus: 4 log units
Fixation Subsystem
• Fixation Wavelength: 635 nm
• Fixation Intensity: 0.9 phot mlx
Operation
• Maximum Test Duration: Rapid Test is 6.5 minutes; Extended Test is 20 minutes
General
• Dimensions: 16.5 cm (height) x 22.3 cm (width) x 34.8cm (depth)
• Weight: 1.1 kg (AdaptDx Pro, AdaptDx Pro Controller and cable)
• AC Charger Specifications: 100-240VAC, 50-60Hz, 0.6A
