Summary of Contents for EPAK DSi6
-
Page 3: Table Of Contents
Table of Contents 1 The digital satellite tracking system....................4 1.1 EPAK®-SatCom system overview....................5 1.2 Safety recommendations........................6 2 Installation............................7 2.1 Standard delivery..........................7 2.2 Installation overview........................7 2.3 Selecting location...........................8 2.4 Mounting surface..........................9 2.5 Planning the cable paths.........................9 2.6 Power supply..........................9 2.7 Drillings............................9 2.8 Mounting the antenna unit......................12... -
Page 5: Epak -Satcom System Overview
1.1 EPAK ® -SatCom system overview Cable types: RX,TX: double shielded coax cable (RG6 type) with F-plugs Antenna Ant: 2 x 2,5 mm² Power cords (included) LAN: Twisted Pair with RJ45 plugs RX TX 230V AC RX TX 230V AC... -
Page 6: Safety Recommendations
1.2 Safety recommendations When mounting the antenna, the distance from the antenna unit to other radiation sources e.g. ➔ radar equipment or other antennas (mobile communication antennas) should be minimum 3 m (11 ft). Simultaneous operation of radar and satellite antenna may damage the satellite antenna if not ➔... -
Page 8: Selecting Location
2.3 Selecting location This illustration shows the importance of a proper location for the antenna unit. Satellite Good view Antenna Antenna Bad view Note that criteria such as an unobstructed view to the satellite and a strong mounting surface are met. Furthermore, no sources of interference, e.g. -
Page 9: Mounting Surface
2.4 Mounting surface A horizontal, solid and steady surface is very important. Make sure that the surface does not have any irregularities! Furthermore, please take into consideration that the weight of the antenna unit is 56 kg or more. Therefore, the surface has to be strong enough to carry the antenna unit, even during the most challenging maritime conditions. -
Page 12: Mounting The Antenna Unit
2.8 Mounting the antenna unit The antenna unit has to be mounted on a solid and steady base parallel to the water surface. Take care that the cable lengths are sufficient, the antenna unit must have an unobstructed view to the satellite and there must be no interference fields (especially mobile communication antennas) nearby. - Page 13 Preparing the Power connector: Housing Insert Chuck Bushing 1. Put bushing and chuck onto the cable. 2. Prepare cable as shown above. 3. Insert the wire into the terminals and fasten the clamping device by a flat screw driver. — 4.
-
Page 14: Control Elements
AC POWER 230V 50 Hz Modem LAN 3 The operation of the EPAK-SatCom system is controlled from the ACU (19'', 2 HU). It is a good idea if you make yourself familiar with the key functions and the indicators: Keys: POWER... -
Page 15: Operation
4 Operation 4.1 Menu tree ON/OFF XXXXXXX serial no. Browse Init Keep pressing counter T XXXX operation time complete Enter Browse software version VA X-XX antenna unit Browse software version Wait GPS VC X-XX control unit Using old data set Preset Browse Choice of satellite... -
Page 16: Preset
States: Init The antenna is in initialization phase and checks the limit switches and motors The antenna waits for valid GPS data from the built in GPS receiver. If no GPS is Wait GPS received or the GPS module is defective, the antenna will hang in this state forever! calibrate Antenna is calibrating the internal compass. -
Page 17: Appendices
APPENDICES A Maintenance The satellite tracking system EPAK-SatCom does not require a lot of maintenance. The following instructions are sufficient to sustain the optimal capacity of the antenna unit: Clean the radome once a month, using fresh water and a mild detergent to remove dirt and salt •... -
Page 18: B Troubleshooting
B Troubleshooting Display Problem Remedy No connection to the antenna unit - Check cable connection to antenna unit (power and no dish antenna cable) - Check antenna unit’s power supply Communication error with antenna Turn unit off and on again ErrorCom unit Power supply for antenna too low... - Page 19 Cannot find a satellite - Check, if superstructures obstruct the view to the satellite Search for stored satellite takes If the location of the vessel changes, the angles of the longer, even though there are no satellite may have changed. Modify angles of the satellite Preset obstructions in the view to the at the new location with the function...
-
Page 20: C Technical Specifications
DSi6 DSi9...
