Page 1
LED TV UV76** (M5 X L20) (M4 X L12) : Depending on model / www.lg.com...
Page 5
ANTENNA/ CABLE IN HDMI IN HDMI IN/ARC USB IN H/P OUT CLOCK...
Page 6
CLOCK Satellite IN OPTICAL DIGITAL AUDIO OUT...
Page 7
AV IN COMPONENT IN VIDEO L/MONO AUDIO R AUDIO VIDEO...
Page 8
HDMI-DVI IN AV IN HDMI IN DVI OUT AUDIO OUT...
Page 11
65UV761H-TB 1455.2 898.1 312.4 840.9 63.5 25.5 24.0 65UV761H-GB AC 100-240 V ~ 50 / 60 Hz...
Page 12
ATAU BENDA LAINNYA YANG MENGELUARKAN API Menyesuaikan menu Televisi LED LG menggunakan layar LCD dengan lampu menghubungkan soket dinding ke input terminal di dinding. DARI PRODUK INI. latar LED.
Page 13
49LV761H-TA Melihat informasi dari program saat ini dan layar. 1107 79.4 14.55 11.3 49LV765H-TA (Tergantung model). 55LV761H-TA PT. LG ELECTRONICS INDONESIA 1241 19.5 16.3 Tombol Navigasi (atas/bawah/kiri/kanan) Memilih menu 55LV765H-TA Kawasan Industri MM2100 Blok G atau pilihan menu. 43UV761H-TA 967.6 617.2...
Page 14
IR CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) Remote control Button Remote control Button (POWER) (Q. Settings) (Power On/Off) (BACK) Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button (INPUT) Remote control Button Remote control Button Number Key 0-9 Remote control Button Alphabet buttons 10-19 ...
EXTERNAL CONTROL Type of Connector : D-Sub 9-Pin Male DEVICE SETUP RS-232C Setup • Image shown may differ from your TV. Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. Connect the serial port of the control device to the RS-232C jack on the Pin name product back panel. 3.5 V RXD (Receive data) NOTE TXD (Transmit data) • RS-232C connection cables are not supplied with the product. IR OUT from TV GND No Connection No Connection (5 V available in some models) No Connection No Connection (12 V available in some models) RS-232C IN (CONTROL & SERVICE) (*Not Provided)
Command Reference List RS-232C Configurations (Depending on Model) 7-Wire Configurations (Standard RS-232C cable) DATA COMMAND1 COMMAND2 (Hexadecimal) PC TV 01. Power 00 to 01 2 3 02. Aspect Ratio (See p. 4) 3 2 03. Screen Mute (See p. 5) 5 5 04. Volume Mute 00 to 01 ...
Transmission / Receiving Protocol 01. Power (Command: k a) ► To control Power On/Off of the set. (Depending on Model) Transmission [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 00 : Power Off 01 : Power On [Command1][Command2][ ][Set ID][ ][Data][Cr] Ack [Command 1] : First command to control the TV.(j, k, m or x) [a][ ][Set ID][ ][OK/NG][Data][x] [Command 2] : Second command to control the TV. ► To Show TV is Power On/Off. [Set ID] : You can adjust the set ID to choose desired monitor ID number Transmission in option menu. Adjustment range is 1 to 99. When selecting Set ID [k][a][ ][Set ID][ ][FF][Cr] ‘0’ , every connected set is controlled. Set ID is indicated as decimal (1 to 99) on menu and as Hexa decimal (0 x 0 to 0 x 63) on transmission/ receiving protocol. [a][ ][Set ID][ ][OK/NG][Data][x] [Data] : To transmit command data.Transmit ‘ FF’ data to read status of * Similarly, if other functions transmit ‘ 0 x FF’ data based on this command.
Page 18
03. Screen Mute (Command: k d) 06. Contrast (Command: k g) ► To select screen mute on/off. ► To adjust screen contrast. You can also adjust contrast in the PICTURE menu. Transmission [k][d][ ][Set ID][ ][Data][Cr] Transmission [k][g][ ][Set ID][ ][Data][Cr] Data 00 : S creen mute off (Picture on) Video mute off Data Min : 0 0 to Max : 64 01 : S creen mute on (Picture off) * Refer to Real data mapping. 10 : Video mute on [g][ ][Set ID][ ][OK/NG][Data][x] [d][ ][Set ID][ ][OK/NG][Data][x] * In case of video mute on only, TV will display On Screen Display(OSD). But, in case of Screen mute on, TV will not display OSD. 07. Brightness (Command: k h) ► To adjust screen brightness. ...
Page 19
09. Tint (Command: k j) 12. Remote control lock mode (Command: k m) ► To adjust the screen tint. ► To lock the front panel controls on the monitor and remote control. You can also adjust tint in the PICTURE menu. Transmission Transmission [k][m][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 : Lock off 01 : Lock on Data Red : 0 0 to Green : 64 * Refer to Real data mapping. [m][ ][Set ID][ ][OK/NG][Data][x] [j][ ][Set ID][ ][OK/NG][Data][x] * If you are not using the remote control, use this mode. When main power is on/off, external control lock is released. * In the standby mode, if key lock is on, TV will not turn on by power on key of IR & Local Key. 10. Sharpness (Command: k k) ► To adjust the screen sharpness. You can also adjust sharpness in the PICTURE menu. 13. Balance (Command: k t) Transmission ► To adjust balance. ...
14. Colour Temperature (Command: x u) 16. Auto Configure (Command: j u) (Only RGB support model) ► To adjust colour temperature. You can also adjust Colour ► To adjust picture position and minimize image shaking Temperature in the PICTURE menu. automatically. It works only in RGB (PC) mode. Transmission Transmission [x][u][ ][Set ID][ ][Data][Cr] [j][u][ ][Set ID][ ][Data][Cr] Data Warm: 00 to Cool:64 Data 01 : To set * Refer to Real data mapping. [u][ ][Set ID][ ][OK/NG][Data][x] [u][ ][Set ID][ ][OK/NG][Data][x] 17. Equalizer (Command : j v) ► To adjust equalize. 15. Energy Saving (Command: j q) ► To reduce the power consumption of the TV. You can also adjust Transmission Energy Saving in PICTURE menu. [j][v][ ][Set ID][ ][Data][Cr] Transmission MSB LSB [j][q][ ][Set ID][ ][Data][Cr] Power Saving Data Frequency Level...
18. Tune Command (Command: m a) 20. Key (Command: m c) ► Select channel to following physical number. ► To send IR remote key code. Transmission Transmission [m][a][ ][Set ID][ ][Data 00][ ][Data 01][ ][Data 02][Cr] [m][c][ ][Set ID][ ][Data][Cr] Data 00 : High channel data Data IR CODES Data 01 : Low channel data ex. No. 47 -> 00 2F (2FH) [c][ ][Set ID][ ][OK/NG][Data][x] No. 394 -> 01 8A (18AH), DTV No. 0 -> Don’t care Data 02 : [Antenna] 21. Control Backlight (Command: m g) 0 x 00 : Analog Main ► To control the backlight. 0 x 10 : DTV Main 0 x 20 : Radio Transmission [m][g][ ][Set ID][ ][Data][Cr] [Cable] 0 x 80 : Analog Main Data Min : 00 to Max : 64 0 x 90 : DTV Main 0 x A0 : Radio [g][ ][Set ID][ ][OK/NG][Data][x] [Satellite] (Depending on Model) 0 x 40 : DTV Main 0 x 50 : Radio Main 22. ...
Page 22
Input Number Data Input1 Input2 Input3 Input4 [b][ ][Set ID][ ][OK/NG][Data][x] * Real data mapping 00 : Step 0 A : Step 10 (Set ID 10) F : Step 15 (Set ID 15) 10 : Step 16 (Set ID 16) 64 : Step 100 6E : Step 110 73 : Step 115 74 : Step 116 CF : Step 199 FE : Step 254 FF : Step 255...
