DEMO MANUAL DC2728A
PARTS LIST
ITEM QTY REFERENCE
Hardware: For Demo Board Only
1 27 E1-E8, E11, E14, E18, E20-E27, E29,
E30, E32, E35-E40
2 3 JP1, JP2, JP3
3 2 J1, J2
4 4 J1, J2 x2
5 2 J1, J2
6 2 J1, J2
7 4 J3, J4, J5, J6
8 3 J7, J12, J13
9 1 J9
10 1 J10
11 1 J11
12 3 XJP1, XJP2, XJP3
13 4 STANDOFF
14 1 SW1,SW2
10
PART DESCRIPTION
TEST POINT, TURRET, 0.094, MTG. HOLE
CONN.,HDR,MALE,1×3, 2mm, THT, STR
STUD, FASTENER, #10-32
NUT, BRASS 10-32
RING, LUG #10
WASHER, TIN PLATED BRASS #10
CONN.,BANANA JACK, FEMALE, THT, NON-
INSULATED, SWAGE
CONN., RF , BNC, RCPT,THT, STR, 5-PIN
CONN.,HDR, MALE, 2×7,2mm, R/A THT
CONN.,HDR, FEMALE, 2×7, 2mm, R/A THT
CONN.,HDR, SHROUDED, 2×6, 2mm, THT, VERT
CONN., SHUNT, FEMALE, 2 POS, 2mm
STANDOFF , NYLON, SNAP-ON, 0.625 (15.9mm)
SWITCH, SUB-MINIATURE SLIDE, DPDT, 0.3A, 6VDC, THT C&K COMPONENTS, JS202011CQN
MANUFACTURER/PART NUMBER
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
PENNENGINEERING, KFH-032-10ET
ANY, 10-32M/S BR PL
KEYSTONE, 8205
ANY, #10EXT BZ TN
KEYSTONE, 575-4
AMPHENOL CONNEX, 112404
MOLEX, 87760-1416
SULLINS, NPPN072FJFN-RC
FCI, 98414-G06-12ULF
WURTH ELEKTRONIK, 60800213421
KEYSTONE, 8834
Rev. 0
