Whirlpool GY396LXP Parts Manual page 7

For Models: GY396LXPB03, GY396LXPQ03, GY396LXPT03, GY396LXPS03
Illus. Part
No. No. DESCRIPTION
1 Support, Drawer
Rail
9757687 Right
9757686 Left
2 9763501BL Support, Front
& Rear
3 Brace, Drawer
4453720 Right
4453721 Left
4 9759965 Bracket, Base
5 Side, Base
9759953 Right
9759954 Left
W10129038
DRAWER PARTS
(Black) (White)
Illus. Part
No. No. DESCRIPTION
6 W10058460 Foot
7 9759943 Brace, Front
8 3196037 Foot Assembly
9 Rail, Storage
9756836 Right
9756838 Left
10 9757806 Drawer
11 Guide, Roller
Includes Roller
9756841 Right
9756842 Left
7
(Biscuit) (Stainless)
Illus. Part
No. No.
12 9760592 Panel, Drawer
13
4453921BL Black
4453921WH White
4453921BT Biscuit
4453921SS Stainless
14
9756674BL Black
9756674WH White
9756674BT Biscuit
15 3196537 Screw
DESCRIPTION
Front, Drawer
Handle, Drawer
