Control Panel Parts - Whirlpool GY396LXP Parts Manual

For Models: GY396LXPB03, GY396LXPQ03, GY396LXPT03, GY396LXPS03
Illus. Part
No. No. DESCRIPTION
1 Control Panel
W10036010 Black
W10036000 White
W10035990 Biscuit
W10035980 Stainless
2 Switch, Infinite
9750638 LR, RF
9750639 RR
9750641 LF
3 9757476 Control, Migration
4 9757119 Bracket, Console
5 3196068 Lens, Indictor (2)

CONTROL PANEL PARTS

(Black) (White)
Illus. Part
No. No. DESCRIPTION
6 W10036100 Bracket, Oven
Control
7 8523265 Housing, Indicator
Light (2)
8 Endcap
Right
9756611BL Black
9756611WH White
9756611BT Biscuit
Left
9756614BL Black
9756614WH White
9756614BT Biscuit
2
(Biscuit) (Stainless)
Illus. Part
No. No.
9
9756659BL Black
9756659WH White
9756659BT Biscuit
10 3196537 Screw
11 9780271 Screw
12 311865 Screw
13 W10078570 Membrane, Switch
DESCRIPTION
Knob
Assembly
W10129038
