Summary of Contents for Wallenstein WX470
- Page 1 OPERATOR'S MANUAL Skid Steer Wood Splitter Rev May-2020 Document Number: Z97155_En...
-
Page 2: Foreword
Operator's Manual. Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Wallenstein dealer or the Distributor if you need assistance, information, or additional copies of the manuals. -
Page 3: Table Of Contents
WX470 Foreword Skid Steer Wood Splitter Table of Contents 1. Foreword ..............2 1.1 Introduction ............2 1.2 Delivery Inspection Report ........4 1.3 Serial Number Location ........5 1.4 Types of Decals on the Machine ......6 2. Safety ..............7 2.1 Safety Alert Symbol ..........7 2.2 Signal Words ............7... -
Page 4: Delivery Inspection Report
Foreword Skid Steer Wood Splitter 1.2 Delivery Inspection Report Wallenstein Skid Steer Wood Splitter www.wallensteinequipment.com To activate warranty, register your product at: This form must be filled out by the dealer at the time of delivery, then signed by the dealer and customer. -
Page 5: Serial Number Location
WX470 Foreword Skid Steer Wood Splitter 1.3 Serial Number Location Always give your dealer the serial number of your Wallenstein product when ordering parts or requesting service or other information. The Serial Number Plate location is shown in the illustration. -
Page 6: Types Of Decals On The Machine
There are Manufactured by: different types of decals for safety, information, and product Wallenstein Equipment Inc., 7201 Line 86, Wallenstein ON N0B2S0, Canada MODEL: ########## TYPE OF VEHICLE/TYPE DE VEHICLE: identification. The following section explains what they are for... -
Page 7: Safety
• Accidents Can Be Avoided DANGER – The policy of Wallenstein Equipment Inc. is to produce products Indicates an imminently hazardous situation that, if not avoided, that are safe and reliable. However, even when using well- will result in death or serious injury. -
Page 8: Safety Rules
WX470 Safety Skid Steer Wood Splitter 2.4 Safety Rules 2.5 Equipment Safety Guidelines Provide operating instructions to operators or employees before The safety of the operator and bystanders is one of the main allowing them to operate the machine. Review these instructions concerns in designing and developing equipment. -
Page 9: Safety Training
WX470 Safety Skid Steer Wood Splitter • Do not attempt any makeshift repairs to the hydraulic lines, • Determine a safe work area location: fittings, or hoses by using tapes, clamps, or cements. The - Area must be clear of stones, branches or hidden hydraulic system operates under extremely high pressure. -
Page 10: Sign-Off Form
WX470 Safety Skid Steer Wood Splitter 2.8 Sign-Off Form The design and manufacture of this product conforms to relative provisions in the following standards: Anyone using this machine must read and thoroughly ISO 4254-1 Agricultural machinery – Safety understand all Safety, Operation and Maintenance information in this manual. -
Page 11: Safety Signs
WX470 Safety Signs Skid Steer Wood Splitter 3. Safety Signs The top (or left-hand) panel shows the safety alert (the potential 3.1 Safety Sign Locations hazard), and the bottom (or right-hand) panel shows the message (how to avoid the hazard). -
Page 12: Safety Sign Explanations
WX470 Safety Signs Skid Steer Wood Splitter 3.2 Safety Sign Explanations 4. Warning! Always wear appropriate Personal 1. Warning! Protective Equipment when using this machine. For example: Keep feet away from falling split wood. Always wear steel toed foot wear while •... -
Page 13: Replacing Damaged Safety Signs
WX470 Safety Signs Skid Steer Wood Splitter 3.3 Replacing Damaged Safety Signs • Always replace safety signs that are missing or have become illegible. Replacement safety signs are available from your authorized distributor, dealer parts department, or the factory. • Always keep safety signs clean and legible. -
Page 14: Familiarization
WX470 Familiarization Skid Steer Wood Splitter 4. Familiarization 4.1 To the New Operator It is the responsibility of the owner or operator to read this manual and to train all other operators before they start working with the machine. Follow all safety instructions exactly. -
Page 15: Splitter Components
WX470 Familiarization Skid Steer Wood Splitter 4.4 Splitter Components 01278 Fig. 3 – Wood Splitter Components 1. Anvil 6. Hydraulic Cylinder 11. Mounting Plate 2. Log Saddle 7. Splitter Frame Latch 12. Return (OUT) Line 3. Tilting Splitter Bed 8. Locking Latch 13. -
Page 16: Controls
WX470 Controls Skid Steer Wood Splitter 5. Controls IMPORTANT! Before starting work with the wood splitter, become familiar with the location and function of all controls. Hydraulic Valve The control valve extends and retracts the wedge to split the wood. The lever on the valve has three positions—Extend, Neutral, and Retract. -
Page 17: Stroke Limiter Accessory
WX470 Controls Skid Steer Wood Splitter Retract 5.2 Stroke Limiter Accessory • Pull the lever fully backwards to retract the wedge. The (As equipped) valve detent holds the lever in Retract allowing a hands-free return cycle. The Stroke Limiter accessory improves productivity when splitting shorter pieces. -
Page 18: Splitter Frame Latch
Controls Skid Steer Wood Splitter 5.3 Splitter Frame Latch WX470 splitters are designed with a pivoting main frame that allows horizontal or fully vertical splitting. To rotate the frame to vertical, follow these steps. 1. Remove the lynch pin from the locking latch and swing it out of the way. -
Page 19: Operating Instructions
The skid steer must be able to easily lift and handle the weight installation, operation, maintenance, repairing, of the wood splitter. The WX470 weighs 315 lb (143 kg). unplugging, or moving. Skid Steer Weight •... -
Page 20: Attaching / Unhooking
WX470 Operating Instructions Skid Steer Wood Splitter 6.4 Attaching / Unhooking The wood splitter is shipped from the factory in a basic, universal configuration that allows it to be mounted to any model skid steer. However, the skid steer must be equipped with remote hydraulic pressure and return connections on the front of the cab frame. -
Page 21: Pre-Operation Checks
WX470 Operating Instructions Skid Steer Wood Splitter 6.5 Pre-operation Checks 6.7 Splitting Logs Efficient and safe operation of the Wood splitter requires that IMPORTANT! Park the wood splitter on a level, dry work each operator reads and understands the operating procedures area free of debris and other objects. - Page 22 WX470 Operating Instructions Skid Steer Wood Splitter 6.7.2 Horizontal Splitting 6. Pile the split wood close to the working area, but do not allow pieces to pile up and clutter the area. A cluttered 1. Place wood or log on the splitter.
-
Page 23: Wood Splitter Break-In Period
WX470 Operating Instructions Skid Steer Wood Splitter 6.9 Transporting 6.9.1 Transport Safety 1. Comply with local laws governing safety and transporting of machinery on public roads. 2. Clean all debris off the splitter. Remove any tools or other loose items. -
Page 24: Storing The Wood Splitter
WX470 Operating Instructions Skid Steer Wood Splitter 6.10 Storing the Wood Splitter After the season's use and the wood splitter is going to be put away in storage, it should be thoroughly inspected and prepared. Repair or replace any worn or damaged components to prevent any unnecessary down time at the start of next season. -
Page 25: Service And Maintenance
PPE. • Where replacement parts are necessary, use only OEM parts to restore your equipment to original specifications. Wallenstein Equipment is not responsible for injuries or damages caused by use of unapproved parts or Fig. 18 – Splitter Bed Slide accessories. -
Page 26: Troubleshooting
The following table lists some problems that may be encountered, with possible causes and solutions. If a problem persists after reading through the Troubleshooting section, contact the local dealer, distributor, or Wallenstein Equipment. Have the machine serial number ready. Problem... -
Page 27: Specifications
WX470 Specifications Skid Steer Wood Splitter 9. Specifications 9.1 Machine Specifications WX470 20 ton Split Force 10 gpm US (38 Lpm) Recommended Hydraulic Oil Flow 24" (61 cm) Split Opening Horizontal / Vertical Orientation 7 Seconds Average Splitter Cycle Time... -
Page 28: Common Bolt Torque Values
WX470 Specifications Skid Steer Wood Splitter 9.2 Common Bolt Torque Values Checking Bolt Torque Imperial Bolt Torque Specifi cations The tables shown give correct torque values for various Torque Value bolts and capscrews. Tighten all bolts to the torque Bolt values specified in the table, unless indicated otherwise. -
Page 29: Hydraulic Fitting Torque
WX470 Specifications Skid Steer Wood Splitter 9.3 Hydraulic Fitting Torque Hydraulic Fitting Torque Tightening Flare Type Tube Fittings Tube Size Flats From Size Torque value 1. Check flare and flare seat for defects that might Across Finger Tight cause leakage. -
Page 30: Accessories
WX470 Accessories Skid Steer Wood Splitter 10. Accessories 4-way Splitting Wedge W4120 01280 Clamp-on Shelf W4211 01281 Stroke Limiter W4213 01282... -
Page 31: Product Warranty
Skid Steer Wood Splitter 11. Product Warranty LIMITED WARRANTY Wallenstein products are warranted to be free of defects in materials and workmanship under normal use and service, for a period of Five Years for Consumer Use Two Years for Commercial/Rental Use from the date of purchase, when operated and maintained in accordance with the opera�ng... -
Page 32: Alphabetical Index
WX470 Alphabetical Index Skid Steer Wood Splitter 12. Alphabetical Index Accessories ................. 30 Replace Damaged Safety Signs ......... 13 Attaching / Unhooking ............20 Return (OUT) Line............... 15 Common Bolt Torque Values ..........28 Safe Condition............... 8 Controls .................16, 19 Safety ..................
