5. Charging volt graph (0:OFF
O N
Mode 1
(100)
1 2 3
O N
Mode 2
(120)
1 2 3
O N
Mode 3
(003)
1 2 3
O N
Mode 4
(020)
1 2 3
O N
Mode 5
(023)
1 2 3
O N
Mode 6
(123)
1 2 3
O N
Mode 7
(000)
1 2 3
Suitable for re-charging
lead storage battery.
Suitable for re-charging
gel battery.
Suitable for re-charging lead
storage battery, which is in good
condition battery (no any sulfated
situation),and completely
disconnected from the devices
it runs.because this mode has
the additional stage, the battery
may reach voltage too high for
them, and the limited current
delivered by the battery charger.
This is not able to provide power
for the devices, and stimultaneously
charge the battery.
Suitable for recovery of sulfated
gel battery, i.e.discharged batteries
unused for long periods or the battery
that never re-charges completely.
This mode should be applied with
the battery completely disconnected
from the devices it runs.
Suitable for recovery sulfated lead
storage battery, i.e. discharged
batteries unused for long periods or
the battery that never re-charges
completely.This mode should be
applied with the battery completely
disconnected from the devices it runs.
DC power supply.
[12.2V (for 12V spec.) /
24.5V (for 24V spec.) ]
DC power supply.
[13.5V (for 12V spec.) /
27V (for 24V spec.) ]
)
standby
orange red orange
LED color
standby
orange red orange
LED color
standby
red red
LED color
standby
green green
LED color
green
green
green
